Image preview - the first page of the document
70102-WW-1


>> Download 70102-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Field Assembly
                                                                                                          70102


For Models           3620, 4302C, 9901, HM0810, HM0810T, M362
Country              European countries, Turkey, South Africa
Description          End plate of Field assembly has been modified as illustrated below.

                       Current                                                        New

                                        End Plate                                                  End Plate




Interchangeability(I/C)
Item No.        Current part            Q'ty I/C           New part                 Q'ty             Note
           Field Assembly 220V                      Field Assembly 220V                    3620: European countries,
    046                                   1   Yes                                    1
           527406-2                                 522638-6                                     Turkey, South Africa
           Field Assembly 240V                      Field Assembly 240V
    046                                   1   Yes                                    1     3620, M362: U.K. (240V)
           527421-6                                 522639-4
           Field Assembly 115V                      Field Assembly 115V                    HM0810, HM0810T:
    048                                   1   Yes                                    1
           527427-4                                 522506-3                                         U.K. (115V)
           Field Assembly 240V                      Field Assembly 240V                    HM0810, HM0810T:
    048                                   1   Yes                                    1
           527430-5                                 528783-5                                         U.K. (240V)
           Field Assembly 220V                      Field Assembly 220V
    038                                   1   Yes                                    1     9901
           527409-6                                 522643-3
           Field Assembly 220V                      Field Assembly 220V
    037                                   1   Yes                                    1     4302C
           528797-4                                 528791-6

Implementation
3620, 9901, HM0810, HM0810T: When the stock of the parts runs out.
4302C: Discontinued since September 1995
M362: Discontinued since April 1993
