Image preview - the first page of the document
70383-WW-1


>> Download 70383-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Modification of Motor Housing Complete
                                                                                                            70383

For Models           1805B, 1806B
Country              All countries
Description          Motor housing complete has been modified as illustrated below.

Motor housing complete

                       Current                                                        New




                                                                                                Brush holders are
                                                                                                press-fit into Motor
                                                                                                housing.

       Set screws M5x8 are used as the stopper                    Screws are eliminated.
       of Brush holders.


Interchangeability(I/C)

 Item No.        Current part               Q'ty I/C          New part                     Q'ty            Note
1805B: 010 Motor Housing Complete                      Motor Housing Complete                     The part No. remains
                                                 1                                          1
1806B: 009 156414-2                                    156414-2                                   the same.


Implementation
1805B: Discontinued since April 1994
1806B: To be implemented from March 2004 production
