Image preview - the first page of the document
70307-WW-1


>> Download 70307-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Change of Hammer, Armature, etc.
                                                                                                             70307


For Models              6932FD

Country                 All countries

Description             The following changes and addition have been implemented to increase power and
                        to comply with UL standard.
                        1. Hammer has been changed.
                        2. The number of winding armature coil has been changed from 13 to 12.
                        3. Leaf spring has been added as illustrated below.




                                                         Leaf spring
                        4. Holder cap has been changed. (For U.S.A. only)

Interchangeability(I/C)
Item No.       Current part                Q'ty I/C        New part                 Q'ty              Note
           Hammer                                   Hammer
    022                                     1    No                                   1
           323996-1                                 324404-5
                                                    Leaf Spring                                  Interchangeable
    045                                                                               1
                                                    232218-7                                          as a set
           Armature                                 Armature
    036                                     1    No                                   1
           619132-8                                 619140-9
           Holder Cap                               Holder Cap
    039                                     2                                         2    For U.S.A. only
           643933-2                                 643982-9
Interchangeability mark ;
The arrow      means that the new part can be substituted for the current.

Note
6932FD for U.S.A., Canada and Mexico is manufactured at MCA.
6932FD for all countries except U.S.A., Canada and Mexico is manufactured at MKC.


Implementation
Immediately upon completion of preparation
