Image preview - the first page of the document
70450-WW-1


>> Download 70450-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                  Change of Base (From Steel to Aluminum)
                                                                                                                      70450

For Models               4324
                         Note: This technical information applies to the products manufactured at MCC plant.
Country                  European countries, Middle Eastern countries, Bhutan, South Africa
Description              Base of steel has been replaced by Base of aluminum, Plate of steel and Countersunk head screws.
                         Due to the change of this specification, optional Kerf board has been also changed, and optional
                         Cover plate has become available for protection of material.

                              Current                                                 New




                                          Base (of steel)                                      Base (of aluminum
                                          (163397-9)                                           (317796-9)

            Kerf Board Set (Optional accessory: 5pcs/set)
            (192733-2)                                       Anti-Splintering device
                                                             (Optional accessory: 5pcs/set)
                                                             (192557-6)
                                                                                          Base plate (of steel)
                                                                                          (345441-6)
                                                                                          Countersunk head screw
                                                                                          M4X8 (912107-9)

                                                                                              Base (of aluminum)
                                                                                              (317796-9)


                                                                                               Cover plate
                                                                                               (Optional accessory)
                                                                                               (417852-6)




Interchangeability(I/C)
 Item No.        Current part                 Q'ty I/C        New part                    Q'ty                 Note
              Base                                      Base
    044                                         1    No                                       1
              163397-9                                  317796-9
                                                        Base Plate
    E08                                                                                       1          Interchangeable
                                                        345441-6                                              as a set
                                                        Countersunk Head
    E09                                                 Screw M4x8                            4
                                                        912107-9
              Kerf Board Set                            Anti-Splitering Device
    F06                                         1    No                                       1
              192733-2                                  192557-6
                                                        Cover Plate
    F07                                                                                       1
                                                        417852-6

Implementation
Already implemented since May, 2004 production
