Image preview - the first page of the document
70457-WW-1


>> Download 70457-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Change of Spindle Complete, Spiral Bevel Gear and Angle Head Set
                                                                                                                    70457

For Models              BFL080F, BFL120F, BFL121F, BFL200F

Country                 All countries
Description             The parts on the subject have been changed.
                        See illustration below for detail of the new parts.

                                                                                             Spiral bevel gear 9




                        Groove for distinction
                        from the current                                      Quality of the gear material
                                                                              and its heating treatment
                                                                              have been changed.

                                                                              Spindle portion have been modified.




                                                 Spindle complete
                                                 (The above illustration is square drive type.
                                                  The actual specifications may differ
                                                  from country to country.)

Interchangeability(I/C)

     Item No.                Current part                 Q'ty I/C             New part                  Q'ty       Note
                        Spindle A Complete
                                                                      Spindle A Complete
        028             9.5mm Square                       1                                                 1
                                                                      153930-5
                        153441-0
                        Spindle B Complete
                        6.35mm E-form                                 Spindle B Complete
        028                                                1                                                 1
                        153483-4                                      153931-3
                        Spindle C Complete
                        6.35mm C-form                                 Spindle C Complete
        028                                                1                                                 1
                        153484-2                                      153932-1
                        Spindle D Complete
                                                                      Spindle D Complete
        028             8mm E-form                         1                                                 1
                                                                      153933-9
                        153485-0
                        Spindle E Complete
                        8mm C-form                                    Spindle E Complete
        028                                                1                                                 1
                        153486-8                                      153934-7
                        Spindle F Complete
                        6.35mm Square                                 Spindle F Complete
        028                                                1                                                 1
                        153487-6                                      153935-5
                        Spiral Bevel Gear 9                           Spiral Bevel Gear 9
        003                                                1                                                 1
                        227446-7                                      227469-5
                    Angle Head Set
BFL080F, BFL120F: F18                                            Angle Head Set
                                                      1                                                      1
BFL121F, BFL200F: F10
                    193729-6                                     193975-1
Interchangeability mark ;
The arrow      means that the new part can be substituted for the current.

Implementation
BFL080F, BFL120F, BFL121F: When the current parts run out
BFL200F: From March 2004 production
