Image preview - the first page of the document
70425-WW-1


>> Download 70425-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Base
                                                                                                        70425


For Models           5903, 5903R (MME products)
Country              All countries
Description          Material of Base has been changed from magnesium to aluminum. Consequently, marking "Mg"
                     indicated on the Base has been changed to "Al" for distinction between current Base and new one.
                     Part number of the Base remains the same.



                                                                    Marking




                                                     Base
                                                  (316556-6)



Interchangeability(I/C)
 Item No.       Current part                 Q'ty I/C       New part                  Q'ty             Note
5903: 065  Base                                       Base
                                              1   Yes                                   1
5903R: 071 316556-6                                   316556-6


Implementation
Immediately upon completion of preparation
