Image preview - the first page of the document
70688-WW-1


>> Download 70688-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Pan Head Screws
                                                                                                           70688
                                                                                                          (Page 1 of 2)

                     BFH040, BFH040F, BFH090, BFH090F, BFH120F, BFL080F, BFL081F, BFL120F, BFL121F,
For Models           BFL200F, BFT040F, BFT080F, BFT120, BFT120F, BFT121F, BFT122F, BFT123F, 6796D,
                     6796FD, 6797D, 6797FD, 6798D, 6798FD
Country              All countries

Description          Pan head screws without resin have been replaced by ones with resin.

                        Current                                                      New
                                                                                                 Resin




      M3x20 Pan head screw without resin (911038-9)             M3x20 Pan head screw with resin (265095-2)
      M4x22 Pan head screw without resin (911143-2)             M4x22 Pan head screw with resin (265145-3)

      Model BFL080F                                      Model BFT040F      M4x22 is used inside Clutch case cover.
            M4x22                                                           So, M4x22 is not visible from the outside.




                M3x20
                                                                            M3x20



Interchangeability(I/C)
BFH040, BFH040F, BFH090, BFH090F, BFH120F
Item No.        Current part              Q'ty   I/C         New part                   Q'ty             Note
           Pan Head Screw M3x20                        Pan Head Screw M3x20
    070                                     8                                               8
           911038-9                                    265095-2
           Pan Head Screw M4x22                        Pan Head Screw M4x22
    021                                     4                                               4
           911143-2                                    265145-3

BFL080F, BFL081F, BFL120F, BFL121F, BFL200F
Item No.        Current part              Q'ty   I/C         New part                   Q'ty             Note
           Pan Head Screw M3x20                        Pan Head Screw M3x20
    064                                     6                                               6
           911038-9                                    265095-2
           Pan Head Screw M4x22                        Pan Head Screw M4x22
    002                                     4                                               4
           911143-2                                    265145-3

BFT040F, BFT080F, BFT122F, BFT123F
Item No.        Current part              Q'ty   I/C         New part                   Q'ty             Note
           Pan Head Screw M3x20                        Pan Head Screw M3x20
    061                                     8                                               8
           911038-9                                    265095-2
           Pan Head Screw M4x22                        Pan Head Screw M4x22
    021                                     4                                               4
           911143-2                                    265145-3

BFT120, BFT120F, BFT121F
Item No.        Current part              Q'ty   I/C         New part                   Q'ty             Note
           Pan Head Screw M3x20                        Pan Head Screw M3x20
    059                                    10                                               10
           911038-9                                    265095-2
                                                                                         70688
                                                                                       (Page 2 of 2)
6796D, 6796FD, 6797D, 6797FD, 6798D, 6798FD
Item No.       Current part                Q'ty I/C              New part       Q'ty   Note
          Pan Head Screw M3x20                           Pan Head Screw M3x20
  050                                       7                                    7
          911038-9                                       265095-2
          Pan Head Screw M4x22                           Pan Head Screw M4x22
  051                                       1                                    1
          911143-2                                       265145-3
Interchangeability mark ;
The arrow       means that the new part can be substituted for the current.

Implementation
BFH040F: From serial No. 1043E (May, 2004)
BFH090 : From serial No. 1934E (May, 2004)
BFT123F: From serial No. 2406E (May, 2004)
BFL080F: From serial No. 3545E (May, 2004)
BFL081F: From serial No. 1110E (April, 2004)
BFL120F: From serial No. 3179E (May, 2004)
BFL121F: From serial No. 3178E (May, 2004)
BFL200F: From serial No. 4081E (May, 2004)
BFT040F: From serial No. 2758E (May, 2004)
BFT080F: From serial No. 2822E (May, 2004)
BFT122F: From serial No. 2530E (May, 2004)
The remaining models: From May, 2004 production
