Image preview - the first page of the document
70955-WW-1


>> Download 70955-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Guide Plate
                                                                                                          70955

For Models            LS1013, LS1013F

Country               All countries

Description           Guide plate has been modified as illustrated below.




                                                                      Current                  New
                                                                                                A hole for positive
                                                                                                stopper has been
                                                                                  33.90 degrees added.




                                                                    Guide plate             Guide plate
                                                                    (344414-6)              (345418-1)




Interchangeability(I/C)
Item No.       Current part                Q'ty I/C          New part                Q'ty           Note
           Guide Plate                                 Guide Plate
    100                                       1                                        1
           344414-6                                    345418-1
Interchangeability mark ;
The arrow      means that the new part can be substituted for the current.

Implementation
For Canada, USA, Brazil, Chile, Mexico, Panama: To be implemented from October, 2004 production
For remaining countries: From serial No. 188562E of LS1013 (July, 2004)
                         From serial No. 5371E of LS1013F (July, 2004)
