TECHNICAL INFORMATION
Subject                   Elimination of Rubber Pin 4, Modification of Base Complete
                                                                                                                  70970

For Models                BO4510, BO4540, BO4560, M901, M904
Country                   All countries
Description               Rubber pin 4 has been eliminated.
                          Accordingly, Base complete has been modified as illustrated below.

                                    Current                                            New
                  Base complete includes Rubber pin 4.




Interchangeability(I/C)
       Item No.             Current part            Q'ty I/C       New part              Q'ty                 Note
                          Base Complete                         Base
          014                                         1   Yes                              1    BO4560
                          152336-4                              414338-1
                          Base Complete                         Base Complete                   BO4510, BO4540, M901, M904
          014                                         1   Yes                              1    The part number remains the same.
                          151232-3                              151232-3
                          Base Complete                         Base Complete
          014                                         1   Yes                              1    M901
                          151233-1                              151233-1
                          Base Complete                         Base Complete
          014                                         1   Yes                              1    BO4510, M904
                          151234-9                              151234-9
BO4510, M901, M904: 015   Rubber Pin 4                                                          A component part of the
BO4540, BO4560: 009                                   1                                         current type of Base complete
                          263002-9

Implementation
BO4510, BO4540: As soon as the current parts run out of stock
BO4560: Discontinued since April, 1995
M901: Discontinued since July, 1992
M904: Discontinued since June, 1992
