Image preview - the first page of the document
70983-WW-1


>> Download 70983-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Ring 16
                                                                                                          70983


For Models           LS1013, LS1040, LS1040F, LS1045

Country              Commonwealth of Dominica, European countries, Bhutan, Canary Islands, Cyprus, Kuwait,
                     Saudi Arabia, Syria, Turkey, Congo, Egypt, Gabon, Morocco, South Africa, Tahiti
Description          Ring 16 has been changed. The new Ring 16 can be also used for models LH1040 and LH1040F.
                     When fitting the new Ring 16 on the spindle of the subject models, the clearance between Ring 16
                     and spindle become fewer than the current.
                     See illustration below for the distinction of the new from the current.


                       Current                                                       New




                                        Stepped                                                   Flat surface




                       Ring 16                                                  Ring 16
                     (257137-6)                                               (257262-3)



Interchangeability(I/C)
      Item No.           Current part             Q'ty I/C       New part                  Q'ty           Note
LS1013: 073          Ring 16                                Ring 16
LS1040, LS1040F: 096 257137-6                       1   Yes                                 1
                                                            257262-3
LS1045: 050

 Implementation
Around August, 2004 production
