Image preview - the first page of the document
70938-WW-1


>> Download 70938-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Name Plate and Tapping Screw
                                                                                                          70938

For Models           DC1414, DC1804
Country              European countries

Description          Each Name plate of the subject battery chargers has been modified to distinguish the FRIWO-made
                     battery chargers from the TAMURA-made battery chargers.
                     Because the component parts of FRIWO-made battery chargers are not interchangeable with those
                     of the TAMURA-made, be sure to control them with the new part numbers listed below in order
                     not to confuse the TAMURA and the FRIWO.
                     The name plate on the FRIWO-made DC1414/DC1804 indicates DC1414F/DC1804F
                     while that on TAMURA-made indicates DC1414T/DC1804T.

                     Tapping screws of DC1804 have been changed as shown below.

Interchangeability(I/C)
 Item No.      Current part               Q'ty I/C      New part                   Q'ty            Note
            Name Plate DC1414                     Name Plate DC1414F
    001                                    1   No                                   1     DC1414
            850977-7                              861107-5
            Name Plate DC1804                     Name Plate DC1804F
    001                                    1   No                                   1     DC1804
            850980-8                              861108-3
            Tapping Screw 4x25                    Tapping Screw 3.5x25
    005                                    4   No                                   4     DC1804
            265999-8                              266350-5

Note
The technical information for TAMURA-made products will be issued after a while.
