TECHNICAL INFORMATION
Subject                Modification of Housing Set and Set Plate,
                                                                                                             71089

                       Addition of Wrench Holder 3.4
For Models             6831D

Country                All countries

Description            Housing set and Set plate has been modified.
                       Wrench holder 3.4 has been added.
                       See illustrations for the details.

                       Current                                                       New
                           Housing set (182658-8)                                            Housing set (183169-6)
                           with Wrench holder                                                without Wrench holder


                                                                                             Wrench holder 3.4
                                                                                             (Part No. 410048-8) is
                                                                                             installed as a standard
                                                                                             equipment.




  Set plate (344121-1)                                    Set plate (343579-1)
        14.0mm             This Housing set does not           10.5mm          The claws on housing set
         (9/16")           allow you to use push               (13/32")        allow you to use push button
                           button type battery.                                type battery.




                                                          How to install Wrench holder 3.4 into the new Housing set
                                                              Put the tail of Wrench holder 3.4
                                                              through the slit on the foot of
                                                              Housing set.


                                                              Bend Wrench holder 3.4 and put the
                                                              tail of Wrench holder 3.4 through
                                                              the slot to fix it with Housing set.


Interchangeability(I/C)

Item No.     Current part                  Q'ty I/C      New part                     Q'ty               Note
         Housing Set                               Housing Set
002, 048                                    1   No                                      1
         182658-8                                  183169-6
           Set Plate                                   Set Plate                                     Interchangeable
    006                                     1   No                                      1
           344121-1                                    343579-1                                           as a set
                                                       Wrench Holder 3.4
    A06                                                                                 1
                                                       410048-8


Implementation
