Image preview - the first page of the document
71143-WW-1


>> Download 71143-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                  Change of Battery Charger
                                                                                                                  71143

For Models               BTD040, BTD042, BTD060, BTD062, BTD120S, BTD150, BTW070, BTW072, BTW120S,
                         BTW121S, BTW150S, BTW151S, DC14SA
Country                  See below.
                         Note: This technical information applies to 220V-240V battery charger.
Description              Battery charger DC12SA has been replaced by DC12SC as illustrated below.
                         The charging time and the performance remain the same.
                         The plug for Australia/New Zealand has been changed to a new type at the same time.

                                       Current                                    New




Interchangeability(I/C)

 Item No.          Current part               Q'ty I/C            New part                 Q'ty               Note
              DC14SA Battery Charger                     DC14SC Battery                           Algeria, Brazil, Chile, Bhutan,
              for Europe (220V)                                                                   Austria, French, Italy, German,
    B01                                        1     Yes Charger KEMA                       1     Netherlands, Poland, Spain,
              193170-3                                   193962-0                                 Switzerland, Sweden, Turkey,
                                                                                                  South Africa, Reunion, Russia
              DC14SA Battery                              DC14SC Battery
    B01       Charger for UK                   1     Yes Charger                            1     UK, Malaysia
              193171-1                                   193963-8
              DC14SA Battery                             DC14SC Battery
    B01       Charger for MAU/MNZ              1         Charger                            1     Australia, New Zealand
              193172-9                                   193964-6
                                                         Charger Case Cover
    010                                                                                     1
                                                         418545-8
                                                         Circuit Board
    015                                                                                     1
                                                         631618-2
              Charger Case Set                           Charger Case
    005                                        1     No                                     1
              183293-5                                   183865-6
              Terminal Base
    009                                        1
              417215-6
              Circuit Board Complete
    015                                        1
              638007-2
              Torsion Spring 14
    002                                        1
              231650-2
DC14SA: 001   Terminal Cover                              Terminal Cover
DC14SC: 003
                                               1     No                                     1
              417214-8                                    418181-0
              Tapping Screw BT 4x20                       Tapping Screw BT 4x20
    016                                        4     No                                     4
              265874-8                                  266346-6
DC14SA: 006   Terminal Unit                             Terminal Unit
DC14SC: 007                                    1     No                                     1
              638017-9                                  638357-5
              Cord Guard
    013                                        1
              682548-0
DC14SA: 012 Vinyl Cord 0.75-2-2.0                         Vinyl Cord 0.75-2-2.0
DC14SC: 011 667987-5                           1                                            1     Australia, New Zealand
                                                          667831-6
                                                          Compression Spring 4
    004                                                                                     2
                                                          231474-6
                                                          Tapping Screw Flange BT3x10
    006                                                                                     1
                                                          266278-7
Interchangeability mark ;
The arrow      means that the new part can be substituted for the current.
Implementation
From July, 2004 production
