Image preview - the first page of the document
71760-WW-1


>> Download 71760-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of M5x10 Pan Head Screws
                                                                                                       71760

For Models             2702, 2703

Country                All countries

Description            Two M5x10 Pan head screws for Rack plate have been replaced by two M5x12 Pan head screws.
                       At the same time, a M5x10 Pan head screw for Gear housing plate has been replaced by
                       a M5x12 Pan head screw.
                       See illustration below for the detail.


                                                      Current                        New
                                           Pan Head Screw M5x10              Pan Head Screw M5x12
                                                (911208-0)                        (911213-7)
    Gear housing plate




                                                      Rack plate




Interchangeability(I/C)
Item No.     Current part                        Q'ty I/C        New part             Q'ty          Note
         Pan Head Screw M5x10                              Pan Head Screw M5x12
002, 084                                          3    Yes                             3
         911208-0                                          911213-7

Implementation
As soon as the current parts in stock run out.
