Image preview - the first page of the document
71962-WW-1


>> Download 71962-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of End Plate of Field Ass'y
                                                                                                               71962


For Models            GA9000, HR5000K, 3705, 9627, 9629S

Country               See below.

Description           Plastic barrier type end plate for Field ass'y has been replaced by fiber plate type end plate.
                      See illustration below.
                      Consequently, the part number of Field ass'y has also been changed.

                                   Current                                       New
                         Plastic barrier type end plate             Fiber plate type end plate




Interchangeability(I/C)
Item No.         Current part                 Q'ty I/C            New part                    Q'ty          Note
           Field Ass'y 220V                               Field Ass'y 220V                             3705 for Europe
    008                                        1    Yes                                          1
           527043-2                                       521563-8                                     except UK
           Field Ass'y 220V                               Field Ass'y 220V
                                               1    Yes                                          1   GA9000 for repair
           528901-5                                       524613-8
           Field Ass'y 240V                               Field Ass'y 240V
    075                                        1    Yes                                          1   HR5000K for UK
           528903-1                                       524834-2
           Field Ass'y 115V                               Field Ass'y 115V
    075                                        1    Yes                                          1   HR5000K for UK
           528913-8                                       524831-8
           Field Ass'y 220V                               Field Ass'y 220V
                                               1    Yes                                          1           9627
           528908-1                                       524828-7
           Field Ass'y 220V                               Field Ass'y 220V
                                               1    Yes                                          1          9629S
           528911-2                                       524838-4


Implementation
From April, 2005 production.
