Image preview - the first page of the document
72098-WW-1


>> Download 72098-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Addition of Controller Protector
                                                                                         72098

For Models            HM1202C, HM1242C
Country               All countries
Description           Controller Protector has been added.

Controller Protector (421914-4):
It is put between Motor housing and Controller
as a shock absorber for the Controller.



                               Motor housing


                                         Controller




Interchangeability(I/C)
Item No.        Current part               Q'ty I/C             New part        Q'ty   Note
                                                         Controller Protector
    094                                                                          1
                                                         421914-4

 Note
When either Controller or Motor housing is worn away in repair of this model,
be sure to replace the worn part by the new one.
If not, the efficiency of controller protector will disappear.

 Implementation
From November, 2004 production
