Image preview - the first page of the document
72144-WW-1


>> Download 72144-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject                 Change of Pin 5 and Lubricant
                                                                                                             72144


For Models              6952, 6953, BTD150, BTW150, BTW151
Country                 All countries
Description             Pin 5 and its lubrication have been changed as described below.


                                 Current                                                       New
              1) Treated with disulfide of molybdenum                    1) Covered with Seal lubricant No.101
    Pin 5         and covered with rust preventing oil.                     (Pt. No. 042010-1A: 100 g/1 set)
              2) Its part No. is 268070-7.                               2) Its part No. is 256253-1.

                          Molybdenum Grease                          It is OK to lubricate the new pin 5 (256253-1)
Lubricant           (Pt. No. 042019-3A: 500 g/1 set)                 with Molybdenum grease instead of Seal lubricant
                                                                     No.101 for repair purpose.


Interchangeability(I/C)
Item No.          Current part               Q'ty I/C             New part                Q'ty        Note
             Pin 5                                        Pin 5
See below.                                    2    Yes                                     2
             268070-7                                     256253-1

Item No. of Pin 5
Model No. 6952         6953   BTD150     BTW150      BTW151
Item No.         026                        028


Implementation
6952: From serial No. 4545E (November, 2004)
The remaining models: As soon as the current parts in stock run out
