Image preview - the first page of the document
72170-WW-1


>> Download 72170-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Name Plate and Motor Housing,
                                                                                                           72170

                     Elimination of Rivet 0-5 and Rubber Pin 4.
For Models           9401, 9402
Country              All countries
Description          Name plate of metal have been replaced by the one of polyethylene telephthalate resin.
                     The tool for attaching the Name plate to Motor housing has also been changed
                     from Rivets to adhesive on the reverse of the Name plate itself.
                     Also, Rubber pin 4 has been eliminated from Motor housing.

                     The new Motor housing doesn't have the holes for the Rivets. Therefore, replace the current
                     Name plate by the new one at the same time.


                                            Motor housing

                                     Name Plate

                                  Rivet




Interchangeability(I/C)
 Item No.      Current part                 Q'ty I/C        New part                    Q'ty              Note
          Name Plate 9401                            Name Plate 9401
   019                                       1    No                                      1    For 9401
          811732-2                                   850166-4
          Name Plate 9402                            Name Plate 9402
   006                                       1    No                                      1    For 9402
          854824-4                                   850176-1
9401: 018 Rivet 0-5                          2
9402: 005 953106-2
          Motor Housing                               Motor Housing                            For 9401
   022                                       1    Yes                                     1    Part No. remains the same.
          156225-5                                    156225-5
          Motor Housing                               Motor Housing                            For 9402
   002                                       1    Yes                                     1    Part No. remains the same.
          157148-0                                    157148-0
9401: 015 Rubber Pin 4                                                                         The component part
                                             1
9402: 072 263002-9                                                                             of Motor housing


Implementation
9401: From serial No. 674599E (November, 2004)
9402: From serial No. 91677E (December, 2004)
