Image preview - the first page of the document
72124-WW-1


>> Download 72124-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Addition of Insulation Washer to Armature
                                                                                                              72124

For Models             4300BA, 4300BV
Country                All countries

Description            Insulation washer (Part No. 681613-2) has been added to Armature ass'y as illustrated below.


                           Current                                                         New
                              109mm                                                     107mm




                                                                                    Insulation washer (681613-2):
 Except for part No. 518256-6 (armature ass'y for UK 110V),                              A component part of
 the current Armature ass'y doesn't have a Insulation washer.                            the new Armature ass'y


Interchangeability(I/C)
Item No.       Current part                 Q'ty I/C         New part                 Q'ty              Note
                                                     Insulation Washer                       For all countries except
    062                                                                                1     UK(240V/110V) and Russia
                                                     681613-2
           Armature Ass'y 115V                       Armature Ass'y 115V                     The part No. remains the
    022                                      1   Yes                                   1
           512062-1                                  512062-1                                same.
           Armature Ass'y 115V                       Armature Ass'y 115V                     4300BV For UK 110V
    022                                      1   Yes                                   1     The current armature ass'y has
           518256-6                                  512062-1
                                                                                             a insulation washer as well as
                                                                                             the new one.
                                                                                             Only part No. has been changed.
           Armature Ass'y 220V                         Armature Ass'y 220V
    022                                      1   Yes                                   1
           512065-5                                    512065-5                              The part No. remains the
           Armature Ass'y 240V                         Armature Ass'y 240V                   same.
    022                                      1   Yes                                   1
           512067-1                                    512067-1
           Armature Ass'y 115V                         Armature Ass'y 115V                   The current armature 115V
                                             1                                         1     is for repair purpose only.
           518620-1                                    512062-1
Interchangeability mark ;
 The arrow      means that the new part is substituted for the current.

 Implementation
As soon as the current parts in stock run out.
(Around December, 2004 production.)
