Image preview - the first page of the document
72297-WW-1


>> Download 72297-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Grip Base
                                                                                                            72297

For Models           6319D, 6339D, 6349D, 8414D, 8434D, 8444D
Country              All countries

Description          Four protrusions have been added to Grip base as illustrated below.
                     Grip ass'y which includes grip base has also been changed.
                     The parts numbers of the grip base and the grip ass'y remain the same.

              Grip ass'y
                                                                  Grip base (See below.)

                                                                          Here are two protrusions,
                                                                          the others are at blind side.




              Grip base

                                 Current                                   New




Interchangeability(I/C)
        Item No.            Current part              Q'ty I/C      New part                  Q'ty          Note
6319D, 6339D, 6349D: A01 Grip Base                              Grip Base                            A component part
8414D, 8434D, 8444D: A02 418768-8                      1    Yes                                1     of Grip Ass'y
                                                                418768-8
                         Grip Ass'y                             Grip Ass'y
          A01                                          1    Yes                                1     6319D, 6339D, 6349D
                         122712-6                               122712-6
                         Grip Ass'y                             Grip Ass'y
          A02                                          1    Yes                                1     8414D, 8434D, 8444D
                         122711-8                               122711-8

Implementation
From January, 2005 production.
