Image preview - the first page of the document
72334-WW-1


>> Download 72334-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Change of Base Complete and Rubber Sleeve 48
                                                                                                           72334

For Models              BO4550, BO4553
Country                 All countries

Description             Base complete and Rubber sleeve 48 have been changed as illustrated below.

                         Current                                                       New
                                          Rubber sleeve 48
                                            (262512-3)

                                                                                       (Rubber sleeve 48 is glued here.)




                                                               Base complete (154657-0) includes Rubber sleeve 48.
        Base complete
         (151236-5)


Interchangeability(I/C)
Item No.        Current part                 Q'ty I/C       New part                   Q'ty            Note
           Base Complete                              Base Complete
  022                                         1    No                                   1
           151236-5                                   154657-0
           Rubber Sleeve 48
  018                                         1
           262512-3


Implementation
BO4553: From December, 2004 production
BO4550: Discontinued since October, 1994
        The change of the part for repair has been implemented around December, 2004 production.
