Image preview - the first page of the document
72427-WW-1


>> Download 72427-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject             Elimination of Rubber Pin 4,
                                                                                                     72427

                    Change of Gear Cover Complete
For Models          9401, 9402
Country             All countries

Description         Rubber pin 4 has been eliminated from Gear cover complete.


                                     Current                                    New
                            Gear Cover Complete
                                                                          Gear Cover
                                  (152204-1)
                                                                          (312549-1)
                      comes with rubber pin 4 (263002-9).




                                           Installation hole               Installation hole
                                                                           and Rubber pin 4
                                 (Rubber pin 4)                            have been eliminated.


Interchangeability(I/C)
  Item No.      Current part               Q'ty I/C            New part                 Q'ty       Note
 9401: 065 Gear Cover Complete               1    Yes
                                                        Gear Cover
                                                                                          1
 9402: 069 152204-1                                     312549-1
 9401: 064 Rubber Pin 4
                                             1
 9402: 073 263002-9

Implementation
To be implemented from March, 2005 production.
