Image preview - the first page of the document
72698-WW-1


>> Download 72698-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Field Ass'y and Terminal Base Complete
                                                                                                        72698
                                                                                                       June, 2005


For Models             HP1010, UH4510, UH4510A, UH6310, UH6310A
Country                All countries using the following parts for repair

Description            The following changes have been implemented to comply with RoHS regulation.
                       HP1010 (220V/ 240V): Field Ass'y with choke coil has been replaced by
                                              the one without choke coil.
                       UH4510, UH4510A,
                       UH6310, UH6310A: Terminal base complete with choke coil has been replaced by
                                           the one without choke coil.

Interchangeability(I/C)

Item No.          Current part               Q'ty I/C           New part               Q'ty            Note
           Field Ass'y 220V                             Field Ass'y 220V
    018                                        1    Yes                                 1     HP1010
           599316-3                                     593178-1
           Field Ass'y 240V                               Field Ass'y 240V
    018                                        1    Yes                                 1     HP1010
           599317-1                                       593179-9
           Terminal Base Complete 72A                     Terminal Base Complete 72A
    019                                        1    Yes                                 1     UH4510, UH6310
           632063-4                                       632062-6
           Terminal Base Complete 72B                     Terminal Base Complete 72B
    019                                        1    Yes                                 1     UH4510A, UH6310A
           632065-0                                       632064-2


Implementation
From July, 2005 production
