Image preview - the first page of the document
72605-WW-1


>> Download 72605-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Housing Set and Name Plate,
                                                                                                                72605

                      Elimination of Makita Label
For Models            6260D, 6270D, 6280D, 8270D, 8280D

Country               All countries

Description         Housing set and and Name plate have been changed as illustrated below.
                    At the same time, Makita label has been eliminated from housing set.
     Change of Name plate




                                                                              Modified: for protection of raised
                                                                                        Makita logo molding

                                                                        Makita (logo) label put on current housing set
                                                                        has been discontinued. New housing set has
                                                                        raised white colored Makita logo
                                                                        molding.




Interchangeability(I/C)
Item No.       Current part               Q'ty I/C           New part                    Q'ty            Note
         Housing Set                                  Housing Set
002, 015                                    1                                             1      For 6260D
         183793-5                                     183822-4
         Name Plate 6260D                             Name Plate 6260D                           For 6260D (Part No.
  003 860433-9                              1                                             1
                                                      860433-9                                   remains the same.)
         Housing Set                                  Housing Set
002, 015                                    1                                             1      For 6270D, 8270D
         183794-3                                     183823-2
         Name Plate 6270D                             Name Plate 6270D                           For 6270D (Part No.
  003                                       1                                             1
         860440-2                                     860440-2                                   remains the same.)
         Name Plate 8270D                             Name Plate 8270D                           For 8270D (Part No.
  003                                       1                                             1
         860977-9                                     860977-9                                   remains the same.)
         Housing Set                                  Housing Set
002, 015                                    1                                             1      For 6280D, 8280D
         183795-1                                     183824-0
         Name Plate 6280D                             Name Plate 6280D                           For 6280D (Part No.
  003                                       1                                             1
         860447-8                                     860447-8                                   remains the same.)
         Name Plate 8280D                             Name Plate 8280D                           For 8280D (Part No.
  003                                       1                                             1
         860978-7                                     860978-7                                   remains the same.)
         Makita Label                                                                           For all the subject models
  014                                       1                                                   (A component part of
         819001-5
                                                                                                current type housing set)
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

Implementation
From April, 2005 production.
