Image preview - the first page of the document
72815-WW-1


>> Download 72815-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Spindle Complete
                                                                                                           72815

For Models           BFL080F, BFL081F, BFL120F, BFL121F, BFL200F
Country              All countries
Description          Spindle complete has been modified to further enhance the fixing strength of spindle and
                     spiral bevel gear 14.
                                                               Spindle

                                                               Spiral bevel gear 14




Interchangeability(I/C)
Item No.         Current part              Q'ty I/C         New part                    Q'ty            Note
           Spindle A Complete                        Spindle A Complete
    028                                     1    Yes                                     1
           153930-5                                  154725-9
           Spindle B Complete                        Spindle B Complete
    028                                     1    Yes                                     1
           153931-3                                  154726-7
           Spindle C Complete                        Spindle C Complete                        The current type of
    028                                     1    Yes                                     1
           153932-1                                  154727-5                                  Spindle complete can still
           Spindle D Complete                        Spindle D Complete                        be used for the repair of
    028                                     1    Yes                                     1     the subject models
           153933-9                                  154728-3
                                                                                               except BFL200F.
           Spindle E Complete                          Spindle E Complete
    028                                     1    Yes                                     1
           153934-7                                    154729-1
           Spindle F Complete                          Spindle F Complete
    028                                     1    Yes                                     1
           153935-5                                    154730-6

Implementation
Since February, 2005 production.
