Image preview - the first page of the document
73243-WW-1


>> Download 73243-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Controller
                                                                                                          73243
                                                                                                         June, 2005


For Models            4304, 4304T, 4305, 4305T, 4306, 9031, 9032, 9911

Country               All countries except Canada and USA

Description           Controller has been changed to comply with RoHS regulation.
                      The assembling way and the wiring remain the same.

Interchangeability(I/C)
 Item No.       Current part            Q'ty I/C             New part           Q'ty                 Note
             Controller 100/115V                        Controller                      For 4304, 4304T, 4305, 4305T,
See below.                                   1    Yes                               1
             631182-3                                   631675-0                        4306, 9911
             Controller 100/115V                        Controller
See below.                                   1    Yes                               1   For 9031, 9032
             631184-9                                   631676-8
             Controller 200/240V                        Controller                      For 4304, 4304T, 4305, 4305T,
See below.                                   1    Yes                               1
             631185-7                                   631677-6                        4306, 9031, 9032, 9911
             Controller 200/240V                        Controller                      For 4304, 4304T, 4305, 4305T,
See below.                                   1    Yes                               1
             631202-3                                   631678-4                        4306, 9911

Item No. of Controller
 4304, 4306 4304T 4305 4305T 9031                9032   9911
    014       010      071 065 027                037    064



Implementation
Around July, 2005 production.
(4305T: Discontinued since May, 2002)
