Image preview - the first page of the document
73441-WW-1


>> Download 73441-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Noise Suppressor
                                                                                                       73441
                                                                                                       July, 2005


For Models             See below.

Country                See below.

Description            Noise Suppressor has been changed as described below.

Model and country
9015B     Austria, France, Germany, Italy, Netherlands, Poland, Russia, Spain, Sweden, Switzerland, UK(110V/240V),
          Bhutan, Turkish, Algeria, Canary Islands, Reunion, South Africa, Australia, New Zealand
9016B     Austria, France, Germany, Italy, Netherlands, Russia, Spain, Sweden, Switzerland, UK(110V/240V), Bhutan,
          Turkish, Algeria, Canary Islands, Reunion, South Africa, China, Australia, New Zealand
9047      Bhutan, New Zealand
9047S     Russia
9049      Italy, Bhutan, South Africa, New Zealand
9057      Australia, New Zealand
9059      South Africa, Australia, New Zealand
9067      Austria, France, Germany, Italy, Netherlands, Poland, Russia, Spain, Sweden, Switzerland, UK(110V/240V),
          Bhutan, Kuwait, Saudi Arabia(220V), Turkey, Algeria, Canary Islands, Reunion, China, Korea,
          Taiwan(110V/220V), Australia, New Zealand
9067S     Austria, France, Germany, Italy, Netherlands, Poland, Russia, Spain, Sweden, Switzerland, UK(110V/240V),
          Algeria, Reunion
9069      Austria, France, Germany, Italy, Netherlands, Poland, Russia, Spain, Sweden, Switzerland, UK(110V/240V),
          Bhutan, Turkey, Kuwait, Saudi Arabia(220V), Algeria, Canary Islands, Reunion, South Africa, China, Korea,
          Taiwan(110V), Australia, New Zealand, Tahiti
9069S     Austria, France, Germany, Italy, Netherlands, Poland, Russia, Spain, Sweden, Switzerland, UK(110V/240V),
          Algeria, Reunion
9077      Austria, France, Germany, Italy, Netherlands, Russia, Spain, Sweden, Switzerland, UK(110V/240V), Turkey,
          Algeria, Canary Islands, Reunion, Australia
9079      Austria, France, Germany, Italy, Netherlands, Russia, Spain, Sweden, Switzerland, UK(110V/240V),
          Turkey, Algeria, Canary Islands, Reunion, South Africa, Australia, New Zealand
9027,
9027S,
9029,
9029S,    Countries using the noise suppressor (Part No. 645214-0)
9037,
9037S,
9039,
9039S

Item No. of Noise suppressor
 9015B, 9016B, 9067, 9047, 9047S, 9049, 9077, 9079          9027, 9027S, 9029, 9029S,
  9067S, 9069, 9069S       9057, 9059                       9037, 9037S, 9039, 9039S
      E01                     049          050                         046

Interchangeability(I/C)
 Item No.       Current part                    Q'ty I/C        New part                Q'ty        Note
           Noise Suppressor                              Noise Suppressor
See above.                                       1   Yes                                 1
           645214-0                                      645088-9


Implementation
As soon as the current parts in stock run out
