TECHNICAL INFORMATION
Subject              Change of Spiral Bevel Gear Set
                                                                                                             73475
                                                                                                        August, 2005


For Models           9015A, 9015B, 9015DB

Country              All countries

Description          Grooves have been disappeared from Spiral bevel gear 12 as illustrated below.
                     Spiral bevel gear set has been changed without change of the part number.
                        Spiral bevel gear 12 (It is a component of Spiral bevel gear set.)
                                     Current                         New




                             Grooves


Interchangeability(I/C)
Item No.      Current part              Q'ty I/C           New part                    Q'ty           Note
         Spiral Bevel Gear Set                     Spiral Bevel Gear Set
006, 038                                  1    Yes                                      1     9015B, 9015DB
         183053-5                                  183053-5
         Spiral Bevel Gear Set                     Spiral Bevel Gear Set
006, 045                                  1    Yes                                      1     9015A
         183627-2                                  183627-2

Implementation
To be implemented from October, 2005 production.
