Image preview - the first page of the document
73404-WW-1


>> Download 73404-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Change of Shoulder Pin 5 and Torsion Spring 17
                                                                                                                73404
                                                                                                                June, 2005


For Models              BJR240, JR140D, JR180D, JR180DMD, JR3000VT, JR3030T, JR3050T
Country                 All countries
Description             Shoulder pin 5 and Torsion spring 17 have been changed as illustrated below.


                                              Current                                    New
                                                    40                                    50



             Shoulder Pin 5



                                                                      Groove for distinction from the current
                                          (256471-1)                              (256492-3)



                                7.0mm                                 8.5mm
                                (9/32")                               (11/32")
            Torsion spring 17


                                              Number of turns: 4.25                Number of turns: 3.25
                                          (231662-5)                               (231687-9)


Interchangeability(I/C)
 Item No.       Current part                   Q'ty I/C          New part                 Q'ty             Note
           Shoulder Pin 5                                  Shoulder Pin 5
See below.                                      1                                              1
           256471-1                                        256492-3
           Torsion Spring 17                               Torsion Spring 17
See below.                                      1                                              1
           231662-5                                        231687-9
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.
Item number of Shoulder Pin 5
BJR240 JR140D         JR180D      JR180DMD          JR3000VT     JR3030T       JR3050T
  001             083                   020              081       088           006
Item number of Torsion Spring 17
BJR240 JR140D         JR180D      JR180DMD          JR3000VT     JR3030T       JR3050T
    012           094                   009              092       099           015

Implementation
JR3050T: From May, 2005 production
The remaining models: As soon as the current parts in stock run out
