Image preview - the first page of the document
73411-WW-1


>> Download 73411-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Safety Cover, Guard Plate and Guard,
                      Addition of Torsion Spring 8, Guard and M4x10 Pan Head Screw
                                                                                                            73411
                                                                                                           June, 2005


For Models            LS0714, LS0714F, LS0714FL, LS0714L
Country               Change of Safety cover: All countries
                      The other change/addition: All countries importing CE-marked products, i.e., European countries,
                                                 Cyprus, Turkey etc.
Description           The following changes/addition have been implemented to meet the requirements of the applicable
                      European Directives.

                       Current                                                         New
                      Safety cover                                             Safety cover
            (For LS0714, LS0714F: 418656-9)                          (For LS0714, LS0714F: 419224-1)
          (For LS0714FL, LS0714L: 418657-7)                        (For LS0714FL, LS0714L: 419223-3)
                                                                                                 Modified




                                    Guard plate                    Guard plate complete
                                    (345438-5)                         (165414-1)




                                       Guard                    Guard
                                    (423333-0)               (421626-9)
                                                                       Guard                       M4x10 Pan head
                                                                 (added: 345649-2)                 screw
                                                                                                   (added: 911114-9)
                                                                  Torsion spring 8
                                                                  (added: 231690-0)

 Interchangeability(I/C)
Item No.        Current part            Q'ty I/C        New part                  Q'ty              Note
           Safety Cover                          Safety Cover                            For LS0714,
    003                                  1                                         1     LS0714F
           418656-9                              419224-1
           Safety Cover                          Safety Cover                            For LS0714L,
    003                                  1                                         1
           418657-7                              419223-3                                LS0714FL
           Guard Plate Complete                  Guard Plate Complete
    038                                  1    No                                   1
           345438-5                              165414-1
           Guard                                 Guard                                         Interchangeable
    040                                  1    No                                   1
           423333-0                              421626-9                                           as a set
                                                 Torsion Spring 8
    197                                                                            1
                                                 231690-0
                                                 Guard
    199                                                                            1
                                                 345649-2
                                                 Pan Head Screw M4x10
    198                                                                            1
                                                 911114-9
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.
 Implementation
LS0714: From serial No. 10154E (June, 2005)
LS0714F: From serial No. 3853E (June, 2005)
LS0714FL: From serial No. 6186E (June, 2005)
LS0714L: From serial No. 2114E (June, 2005)
