73436-WW-1


>> Download 73436-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Motor Housing Cover
                                                                                                            73436
                                                                                                            June, 2005

For Models            HM1800, HM1801, HM1810

Country               All countries
Description           Motor housing cover has been changed to emphasize Makita logo.
                      See shown below.

                          Current                                                        New
                      Regarding China and Hong Kong only,               Regarding China and Hong Kong only,
                      a caution label in Chinese is put on.             a caution label in Chinese is put on.




                         Makita logo label is put on Motor
                         housing cover set for model                    White colored Makita logo is stamped.
                         HM1801 and HK1810.


Interchangeability(I/C)
For HM1801 and HM1810
Item No.        Current part             Q'ty I/C            New part             Q'ty               Note
           Motor Housing Cover                                                           All countries except Hong
                                                    Motor Housing Cover
    048    Set                            1                                        1
                                                    419324-7                             Kong and China
           183984-8
           Motor Housing Cover                      Motor Housing Cover
    048    Set                            1         Complete                       1     Hong Kong and China
           183985-6                                 154810-8
           Makita Logo Label                                                             A component part of
    134                                   1
           819213-0                                                                      Motor housing cover set
                                                                                         (Part No. 183984-8/183985-6)

For HM1800
Item No.        Current part             Q'ty I/C         New part                Q'ty                Note
           Motor Housing Cover                      Motor Housing Cover                  For all countries
    060                                   1                                        1
           414788-0                                 419324-7                             except Hong Kong and China
           Motor Housing Cover                      Motor Housing Cover
                                                                                         For Hong Kong and China
    060    Complete                       1         Complete                       1     with caution label in Chinese
           150852-0                                 154810-8
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

Implementation
HM1800: From serial No. 37360E (June, 2005)
HM1801: From serial No. 1431E (June, 2005)
HM1810: From serial No. 2179E (May, 2005)

(HM1801 and HM1810 for Hong Kong and China: From initial production.)
