Image preview - the first page of the document
73998-WW-1


>> Download 73998-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Dust Nozzle
                                                                                                   73998
                                                                                               September, 2005


For Models           BLS712, BLS820, LF1000, LS0711B, LS0711Z, LS711D, LS0713, LS0713F, LS0713FL,
                     LS0714, LS0714F, LS0714FL, LS0714L, LS0715, LS0715F, LS0715FL, LS800D, LS0811,
                     LS0813, LS0813F, LS0813FL, LS1013, LS1013F, LS1212, LS1212F, LS1214, LS1214F
Country              All countries
Description          Dust nozzle has been changed as illustrated below.

                                      Current                       New




                                     Dust nozzle                  Dust nozzle
                                     (416133-5)                   (419277-0)


Interchangeability(I/C)
 Item No.      Current part                 Q'ty I/C         New part            Q'ty          Note
           Dust Nozzle                                 Dust Nozzle
See below.                                   1     Yes                             1
           416133-5                                    419277-0

Item No. of Dust Nozzle
BLS820 LF1000 LS0711B LS0713 LS0713F LS0713FL LS0714 LS0714F LS0714FL LS0714L LS0715 LS0715F
 029    083     041            032                         033                      032
LS0715FL LS0813 LS0813F LS0813FL LS1013 LS1013F LS1212 LS1212F LS1214 LS1214F BLS712 LS0711Z
  032             037                        057                    070        032     041
LS711D      LS800D   LS0711
  032         029     076

Implementation

BLS712, LS711D, LS800D: Discontinued since July, 2003
BLS820: From serial No. 2343E (November, 2005)
LS0711Z: Discontinued since March, 2003
LS0714: From serial No. 10702E (August, 2005)
LS0714F: From serial No. 4413E (August, 2005)
LS0714FL: From serial No. 6726E (August, 2005)
LS0714L: From serial No. 2437E (August, 2005)
LS0811: Discontinued since January, 2003
LS1013: From serial No. 207276E (July, 2005)
LS1013F: From serial No 6345E (July, 2005)
LS1212: From serial No. 38107E (August, 2005)
LS1214: From serial No. 15667E (July, 2005)
LS1214F: From serial No. 5607E (August, 2005)
LS0813F: From serial No. 2251E (August, 2005)
LS1013L: From serial No. 1322E (August, 2005)
LS1214: From serial No. 1527E (August, 2005)
LS713FL, LS813FL, LS0711B, LS0713, LS0715, LS0715F, LS1213: As soon as the current parts in stock run out
