Image preview - the first page of the document
74194-WW-1


>> Download 74194-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Set Plate
                                                                                                              74194
                                                                                                         September, 2005


For Models            See below.

Country               All countries

Description           Neither length or color of Set plate has been changed to unify the two kinds of parts
                      as outlined below.

                                                     Current                              New
                                             Set plate (343652-7)
          LS1011, LS1011N, LS1030
                                         110mm (4-5/16") in length, black
        BLS712, LH1040, LH1040F,
        LS711D, LS0711B, LS0711Z,                                               Set plate (345709-0)
        LS0713, LS0713F, LS0714,                                            140mm (5-1/2") in length, black
                                               Set plate (344049-3)
        LS0714F, LS0714FL, LS0714L,
                                             140mm (5-1/2") in length,
        LS0811, LS0813, LS0813FL,
                                                  yellowish gray
        LS1030N, LS1040, LS1040F,
        LS1045, LS1211, LS1212,
        LS1212F

Interchangeability(I/C)
  Item No.       Current part                Q'ty I/C        New part                   Q'ty              Note
LS1011,     Set Plate                                  Set Plate                               The component of Set plate
                                              1    Yes                                   1     assembly
LS1030: A02 343652-7                                   345709-0
             Set Plate Ass'y                           Set Plate Ass'y                         Though the component is
 See below.                                   1    Yes                                   1     changed as mentioned above,
             122472-0                                  122472-0
                                                                                               the part number remains the
LS1011:F26 Holder Set                                  Holder Set                              same.
                                              1    Yes                                   1
LS1011N: F01 192118-2                                  192118-2
LS1030: F14

Item No. of Set Plate Ass'y
 A01    LH1040, LH1040F
 F01    BLS712, LS0713, LS0713F, LS0714, LS0714F, LS0714FL, LS0714L, LS0813, LS0813FL, LS1212
 F02    LS711D, LS0711B, LS0711Z, LS1030N, LS1040F, LS1045, LS1212F
 F03    LS0811
 F04    LS1040
 F09    LS1211

Implementation
From August 2005 production.
