Subject               Change of Ball Bearing 629LLB
                                                                                                 August, 2005

For Models            9553B, 9553NB, 9554NB, 9555B, 9555NB, 9556NB, 9556PB
                      9557NB, 9557PB, 9558NB, 9558PB
Country               All countries

Description           The following Ball Bearing 629LLB has been changed.

                                                        Current                New
                            Indication on the seal         CHL            NSK, NTN

                            Part number                   210071-1            210053-3

                                   Ball Bearing 629LLB

                                   (Gear housing cover)

Item No.         Current part             Q'ty I/C           New part                    Q'ty   Note
           Ball Bearing 629LLB                        Ball Bearing 629LLB
    010                                     1                                             1
           210071-1                                   210053-3
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

9553B, 9555B
From initial production.
The remaining models
For China: From August, 2005 production,
All countries except China: Around September, 2005 production.
