8035NB-TE


>> Download 8035NB-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION
       Models No.            8035NB
                                                                                                     New Tool


       Description           MAKITA Rotary hammer

CONCEPTION AND MAIN APPLICATIONS
   Based on the model 8700N, the conductive
   part is composed of the double insulation structure,
   enabling the safety operation.




   Specifications
     Voltage (V)               Current (A)                Cycle (Hz)   Continuous rating input (W)
   Single-phase100-               8                        50-60               760

No load speed       Rotation per minute(rpm)         200/min
                    Blows per minute(bpm)            2800/min
Overall length                                       425mm
Net weight(kg)                                       7.8kg
Power supply cord(m)                                 5m
Capacities     T.C.T. drill bit                      35mm
               Core bit                              105mm


   Standard equipment
     Spanner 9.23
     Oil vessel(100 cc contained)
     Dropping pipette
     Steel case


   Optional accessories
     Carbide drill
     Taper shank carbide drill
     Bull point
     Cold chisel
     Core bit
     Adapter
     Anchor
     Scaling chisel
     Scoop
     Holder driver
     Turning handle
     Cotter
     * The parts shown above are common for the conventional ones.


   Features and benefits
     Same as the model 8700N and composed of the double insulation structure.



     The standard equipment for the tools shown may differ form country to country
Capacity
 Same as the model 8700N

 Disassembling/assembling
  a) Fastening torque of the motor housing and the handle(R/L) --- 30 kg-cm
  b) Fastening torque of the crank housing and the handle(R/L) --- 40 kg-cm
  c) Fastening torque of the crank housing and the motor housing --- 40 kg-cm
