Image preview - the first page of the document
8280D-TE


>> Download 8280D-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION
    Models No.              8280D
                                                                                                             PRODUCT
                                                                                                                P1/7

    Description             Cordless Percussion Driver Drill                                             L

CONCEPT AND MAIN APPLICATIONS
   Models 8280D has been developed by adding percussion mechanism to
   Model 6280D for a compact, yet powerful and durable 14.4V cordless percussion
   driver drill. Its brief advantages are;                                                H
   *Compact design with an overall length of only 214mm (8-3/8")
   *Very versatile with 3 work modes; Percussion drill, Drill, Screwdriver
   *All metal gear construction for extra-high transmission durability                                                W
   This new product is available in the variations listed below.

                                   Battery                             Rechargeable
    Model No.                                               Charger                            Dimensions: mm (")
                                 Type               Q'ty               flashlight
    8280DZ                      without                     without       without         Length (L)     214 (8-3/8)
                                                                                          Width (W)     94 (3-11/16)
    8280DWAE                                          2                   without
                    Ni-Cd Battery 1422 (2.0Ah)                                            Height (H)    243 (9-9/16)
    8280DWALE                                         2                   ML140
    8280DWE                                           2                   without
                    Ni-Cd Battery 1420 (1.3Ah)
    8280DWLE                                          2     DC1414        ML140
    8280DWPE                                          2                   without
    8280DWPLE       Ni-Cd Battery PA14 (1.3Ah)        2                   ML140
    8280DWPE3                                         3                   without

 Specification
               Voltage: (V)                                                     14.4
    Battery    Cell                                                            Ni-Cd
               Capacity: (Ah)                   1.3 Ah (Battery 1420, PA14)                 2.0 Ah (Battery 1422)
    No load speed:          High speed                                        0 - 1,200
             min-1=rpm      Low speed                                          0 - 350
    Impact per minute:      High speed                                       0 - 18,000
            min-1=bpm       Low speed                                         0 - 5,250
    Chuck capacity: mm ( " )                                            0.8 - 10 (1/32 - 3/8)
                   Steel: mm ( " )                                             10 (3/8)
    Capacities     Wood: mm ( " )                                               25 (1)
                   Masonry: mm ( " )                                           10 (3/8)
    Max. fastening          Hard joint                                            36
    torque: N.m             Soft joint                                            20
    Torque adjustment                                                 16 stages plus drill mode
    Net weight: kg (lbs) [includes battery]                                   1.7 (3.7)

  Standard equipment
                                               8280DWAE, 8280DWALE, 8280DWE,
    Model No.                8280DZ                                                           8280DWPE3
                                               8280DWLE, 8280DWPE, 8280DWPLE
    (+) (-) Bit 2-65           1                                 1                                  1
    Battery cover              No                                2                                  3
    Plastic carrying case      No                               Yes                                Yes
   Note: The standard equipment listed above may differ from country to country.

 Optional     accessories
   Battery 1420      Battery 1434         Charger DC1414     Automotive charger DC1422        Assorted drill bits for wood
   Battery PA14      Battery 1435         Charger DC1804     Automotive charger DC1822        Assorted drill bits for steel
   Battery 1422      Battery 1435F        Charger DC1439                                      Assorted driver bits
                                                                                              Assorted TCT drill bits
                                                                                                                         P2/7
Features           and benefits

 All Metal Gear Construction                                                          Compact Design with an Overall
 For extra-high transmission durability                                               Length of Only 214mm (8-3/8")
                                                                                       For outstanding maneuverability
                                                      214mm
                                                      (8-3/8")




                                                                                                    Rubberized Soft Grip
                                                                                                  Provides comfortable operation
                                                                                                  with better control.
 Keyless Chuck with
 Anti-Loosen Mechanism
                                                                                                  Hand strap is attachable.


 Note: The boss for set plate is eliminated
       from the grip end of the both models.

Comparison             of products
                                                Percussion driver drill                        Driver drill
                                  Model No.           Makita               Makita                   A                    B
 Specifications                                        8280D               6280D                   A                  B
                Cell                                   Ni-Cd               Ni-Cd                 Ni-Cd              Ni-Cd
 Battery
                Capacity: (Ah)                          1.3                 1.3                   1.3                1.4
 No load speed:        High speed                    0 - 1,200            0 - 1,200             0 - 1,400          0 - 1,200
 min-1=rpm             Low speed                       0 - 350             0 - 350               0 - 400            0 - 400
 Blows per minute:     High speed                    0 - 18,000
 min-1=bpm                    Low speed              0 - 5,250
 Lock torque: N.m (in.lbs)                            30 (260)            30 (260)              39 (350)           35 (300)
 Max. fastening               Hard joint              36 (313)            36 (313)                                35 (300)
 torque: N.m (in.lbs)         Soft joint              20 (174)            20 (174)                                23 (200)
                                                                                                                  Johnson
                                                     Mabuchi               Mabuchi           Competitor A's
 Motor                                                                                                         (equivalence to
                                                    RS-550VC              RS-550VC           own production
                                                                                                              Mabuchi RS-775)
                       Sleeve Type                     Dual                 Dual                 Dual                Single
 Keyless chuck
                       Chuck capacity: mm (")         10 (3/8)             10 (3/8)             10 (3/8)            10 (3/8)
                       Steel: mm (")                  10 (3/8)             10 (3/8)             10 (3/8)           11 (7/16)
 Capacities            Wood: mm (")                    25 (1)               25 (1)             32 (1-1/4)         32 (1-1/4)
                       Masonry: mm (")                10 (3/8)
                                                    16 stage +            16 stage +           18 stage +         15 stage +
 Torque adjustment
                                                    drill mode            drill mode           drill mode         drill mode
               Length: mm                                214                  192                  218                228
                       (")                             (8-3/8)             (7-9/16)              (8-5/8)              (9)
  Dimensions




               Width: mm                                  94                   94                   82                 86
                      (")                            (3-11/16)            (3-11/16)              (3-1/4)            (3-3/8)
               Height: mm                                243                  243                  229                252
                       (")                            (9-9/16)             (9-9/16)                (9)              (9-7/8)
 Net weight: kg (lbs)                                    1.7                 1.6                   1.9                1.8
 [includes battery]                                     (3.5)               (3.5)                 (4.2)              (3.9)
 Soft grip                                               Yes                 Yes                   No                Yes
 Bit holder                                              No                  No                    Yes               Yes
                                                                                                                  P3/7
Comparison      of products
 Numbers in chart below are relative values when the capacity of Model 6228D/ 8402VD is indexed at 100.
 Note: The test results depend to a great extent on the hardness of the material, etc.

 Comparison in Drill Mode (Wood drilling)
 [Test 1]
 Test Conditions: Drilled holes through 60mm thick Lauan with
