Image preview - the first page of the document
8390D-TE


>> Download 8390D-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
   Model No.                 8390D
                                                                                                             PRODUCT
                                                                                                               P1/7

   Description                                                                                           L
                             Cordless Percussion Driver Drill 13mm

CONCEPT AND MAIN APPLICATIONS
   Model 8390D has been developed by adding percussion mechanism
   to Model 6390D.                                                                                                    H
   Its brief features are:
   *High torque delivered by powerful Type 775 motor
   *Compact design with an overall length of only 239mm (8-5/8")
   This new product is available in the following variations.
                                    Battery                                                        W
                                                      Battery cover
     Model No.                   type         quantity (quantity) Charger Flash light            Dimensions: mm (")
    8390DZ                  without             ---         ---        without                Length (L)    239 (9-3/8)
                                                                                  without
    8390DWAE          1822 (Ni-Cd 2.0Ah)         2           2                                Width (W)      95 (3-3/4)
    8390DWALE         1822 (Ni-Cd 2.0Ah)         2           2                    ML180       Height (H)    252 (9-7/8)
    8390DWPE          PA18 (Ni-Cd 1.3Ah)         2           2        DC1804
                                                                                  without
    8390DWPE3         PA18 (Ni-Cd 1.3Ah)         3           3
    8390DWPLE         PA18 (Ni-Cd 1.3Ah)         2           2                    ML180
    Note: All of the above models come with the items listed below
    in the "Standard equipment" in addition to the items listed above.

    Specification
                Voltage: V                                         18
    Battery     Cell                                              Ni-Cd
                Capacity                  1.3 Ah (Battery PA18)       2.0 Ah (Battery 1822)
    No load speed: (min -1= rpm)                    Low: 0 - 350, High: 0 - 1,200
    Blows per minute: Low                                     0 - 5,250
    (min -1= bpm)         High                               0 - 18,000
    Chuck capacity: mm ( " )                              1.5 (1/16) - 13 (1/2)
                       Steel                                    13 (1/2)
    Drilling capacity: Wood                                    36 (1-7/16)
    mm (")             Masonry                                  13 (1/2)
    Max fastening      Soft joint                                  27
    torque: N.m        Hard joint                                  42
    Electric brake                                                 Yes
    Variable speed control                                         Yes
    Reverse switch                                                 Yes
    Net weight*: kg (lbs)                                       2.3 (5.1)

    *includes battery 1822.

    Standard equipment
    Philips bit 2-65 ............... 1
    Plastic carrying case ....... 1
    Note: The standard equipment for the tool shown may differ by country.

    Optional       accessories
    Battery 1822           Charger DC1804         Assorted drill bits for wood
    Battery 1834           Charger DC1822         Assorted drill bits for steel
    Battery 1835                                  Assorted driver bits
    Battery 1835F                                 Assorted TCT drill bits
    Battery PA18
                                                                                                     P2/7
Features     and benefits
                                                     239mm
     Compact Design                                  (9-3/8")                Powerful Type-775 Motor
  with an Overall Length                                                     Delivers High Torque.
  of Only 239mm (9-3/8")
Provides outstanding
maneuverability.                                                                                                 *
(About 25mm shorter than 8443D)                                                  Rubberized Soft Grip
                                                                                Provides comfortable operation
  13mm (1/2") Chuck                                                             with better control.

                                               *                                                                 *
   All Metal Gear Construction                                                   Hand strap is attachable.
 Ensures extra-high transmission durability.
 (Uses the same gear assembly as
  6260D/8270D series models.)                                                   PA Type battery
                                                                                is also available.
*Same advantage as Model 8270D

Comparison        of products
 Specification Comparison
                                 Model No.                Makita                      A
 Specifications                                             8390D                     A
                       Voltage: V                             18                     18
 Battery               Capacity: (Ah)              1.3 (PA-18)/ 2.0 (1822)         **1.4
                       Cell                                 Ni-Cd                   Ni-Cd
 Charging time: min.                                 30/ 45 (w/ DC1804)              60
                                    Low                    0 - 350                 0 - 400
 No load speed: min-1=rpm
                                    High                  0 - 1,200               0 - 1,400
                                    Low                   0 - 5,250               0 - 5,200
 Blows per minute: min-1=bpm
                                    High                0 - 18,000                0 - 18,200
 Lock torque: N.m (in.lbs)                               38 (340)                  39 (345)
                                    Hard joint              42
 Max. fastening torque: N.m                                                          N/A
                                    Soft joint              27
                                    Wood                36 (1-7/16)               32 (1-1/4)
 Capacity: mm (")                   Steel                13 (1/2)                  13 (1/2)
                                    Masonry              13 (1/2)                  13 (1/2)
                                                         Mabuchi                   Johnson
 Motor
                                                        RS775-VC                    HC785
                       Sleeve type                        Dual                       Dual
 Keyless chuck
                       Chuck capacity: mm (")            13 (1/2)                  13 (1/2)
                                                        16 stages +              22 stages +
 Torque adjustment
                                                        drill mode               drill mode
 Metal gear                                                 Yes                      No
 Bit holder                                                 No                       Yes
 Side handle                                                No                       No
 Soft grip                                                 Yes                       Yes
                       Length: mm (")                   239 (9-3/8)              260 (10-1/4)
 Dimensions            Width: mm (")                     95 (3-3/4)              74 (2-15/16)
                       Height: mm (")                   252 (9-7/8)              255 (9-7/8)
 Net weight: kg (lbs) [includes battery]                  2.3 (5.1)                2.3 (5.1)
                                                   Plastic carrying case     Plastic carrying case
 Standard equipment
                                                             Bit                      Bit
 **the capacity actually measured
                                                                                                                                              P3/7
Comparison                                of product
Performance Comparison
Note: 1. With 2.0Ah Ni-Cd battery, Makita models were tested.
      2. The test results depend to a great extent on the hardness of materials, etc.
      3. The numbers in the bar graphs are relative values when the capacity of Model A of the competitor A
         is indexed at 100.
MASONRY DRILLING
Test Conditions: Drilled holes in brick to a depth of 40mm with diameter 10.5mm TCT drill bit.

                                                    [Work speed]                                             [Work Volume]
                                           (the time required to drill a hole)                       (on a single full battery charge)
                                                        Slow         Fast                           Few                           Many

Makita 8390D                                                   100        9.5 sec                                           174    84 holes

Competitor A
                                                               100                                        100
     Model A

                                          0              50         100         150       0        50           100       150           200    250



Clutch
The Graduation on Torque Adjusting Ring and Corresponding Fastening Torque
(The Torque When Clutch Is Disengaged)
                    [ft.lbs] (kg.cm) N.m
                    [5.1] (70)                  7

                    [4.4] (60)                  6

                    [3.6] (50)                  5
Fastening Torque




                    [3.0] (40)                  4

                    [2.2] (30)                  3

                    [1.5] (20)                  2

                    [0.7] (10)                  1

                       [0]          (0)         0

   Graduation on the
   torque adjusting ring                            1     2               4           6        8           10            12             14      16


                     Machine screw                             M4                                  M5                                   M6
 Applicable screw




                                 Soft wood                                                    dia. 3.5x22mm
                    Wood screw




                                 (pine, etc.)                                                                         dia. 4.1 x 38mm
                                 Hard wood                                                          dia. 3.5 x 22mm
                                 (lauan, etc.)                                                                             dia. 4.1 x 38mm

16 Stage torque settings allow for;
1) Appropriate torque setting in tightening M4 to M6 machine screws
2) Precision matching of surfaces with wood screws regardless of the screw size or the hardness of wood
                                                                                                                 P4/7
Repair
[1] Removal/Installation of Drill Chuck
 When replacing Gear assembly, remove drill chuck beforehand as described below.
 (It is not necessary to remove Drill chuck when disassembling Housing only.)
  REMOVAL
 1) After fully opening Chuck jaws, remove the chuck screw (M6x22 (-) Flat head screw) by turning it clockwise.
    If it is difficult to remove, use a Makita Impact wrench.
 2) Slide Speed change lever to the position of "Low", and turn Change ring to "Drill mode".
    And then secure one end of a hex wrench with Chuck jaws. Hold the machine firmly, and then remove Drill chuck
    by hitting the other end of the hex wrench using plastic hammer to turn Drill chuck counterclockwise. (Fig. 1)
  INSTALLATION
 1) Secure one end of a hex wrench with Chuck jaws, and the other with vise.
    Shift Speed change lever to "Low", and set the machine in the mode of drilling in forward rotation. Hold the grip
    of the machine firmly so that your hand cannot be pulled away by reaction torque. And then fasten Spindle to Drill
    chuck by pulling the trigger of Switch until Spindle is locked. (Fig. 2)
    Note: Release the trigger of Switch just after Spindle is locked. Do not keep on pulling the trigger for longer than
           one second.
 2) Fasten Drill chuck to Spindle with the chuck screw (M6x22 (-) Flat head screw) by turning it counterclockwise.
 Fig. 1                                                        Fig. 2

    Slide Speed change lever          Turn Change ring
    to the position of "Low".         to "Drill mode".              Shift Speed change               Turn Change ring
                                                                    lever to "Low".                  to "Drill mode".

                                            Hex wrench
                          2 4




                                                                                                            Hex wrench
                          6 8




                                                                                                                    Vise




   Important:
   In order not to break Spindle, be sure to put the three          Push in R/F change lever
   circled portions of the tool on work bench, and place            for forward rotation mode.
   Drill chuck outside the workbench.


[2] Removal/Installation of Motor from/on Gear Assembly
  REMOVAL
 1) Pull Motor out of Gear assembly while turning it in the counterclockwise direction when viewed from the terminal
    end of Motor. (Fig. 3)
 2) Remove Motor bracket from Motor by removing two Pan head screws. Now Motor can be replaced (Fig. 4)
 Fig. 3                                                              Fig. 4

                                  Motor                                       Motor bracket              Motor


                                                Pull Motor
                                                while turning
                                                counterclockwise.


      Gear assembly             Terminals                               Pan head screw
                                                                                                                       P5/7
Repair
[2] Removal/Installation of Motor from/on Gear Assembly
  INSTALLATION
 1) Place Motor bracket as illustrated in Fig. 5,   Fig. 5
    and fasten it to Motor with two Pan head
    screws.                                           Place Motor bracket                    Speed change lever side
 2) Aligning the protrusions on Motor bracket         so that its protruding
    with the grooves in Gear assembly,                side is positioned on        Side without protrusion       Red marking
    assemble Motor to Gear assembly. (Fig. 6)         the opposite side to the
 3) Assemble Motor to Gear assembly while             red marking on Motor.
    turning it in the clockwise direction when
    viewed from the terminal end of Motor.
    (Fig. 7)


                                                     Pan head screw
                                                                                                                       Motor
                                                                   Motor bracket                  Protruding side

                                                                                                Trigger switch side

 Fig. 6                                                                   Fig. 7
                                          Grooves in Gear assembly




   Protrusions on
   Motor bracket
                                                                                                                 Terminals
                                                    Gear assembly                Gear assembly        Motor
                                            Motor bracket
                                  Motor

[3] Installing Speed change Lever
                                                                                             Fig. 8
 1) Make sure that two Compression springs are set in place on Speed change lever
    as illustrated in Fig. 8.                                                                 Compression springs
 2) Install Speed change lever onto the protrusion on Gear assembly as illustrated
    in Fig. 9.
   After installation, slide Speed change lever to either side. (Fig. 10)



                                                                                                            Speed change lever

 Fig. 9                                                                            Fig. 10

     Speed change lever


                                                                                                                 Speed change
                                                                                                                 lever
                                                              Compression
                                                              springs

                                                             Protrusion

     Protrusion
                                    Gear assembly Motor
                                                                                                              P6/7
Repair
[5] Installing Leaf spring Onto Housing (L)
 Before installation of inner electrical parts,   Fig. 11
 remember to set Leaf spring in place on
 housing (L) as illustrated in Fig. 11.              Housing (L)
                                                                                     Leaf spring




[6] Installing Change Ring on Gear Assembly
 Install Change ring on Gear assembly as illustrated in Fig. 12.
 Fig. 12

                             ribless portion

                       Rib
                                                             the widest protrusion




               Change ring
                                  Gear assembly

      Aligning the ribless portion on Change ring
      with the widest protrusion on Gear assembly,
      install Change ring on Gear assembly.


[7] Installing F/R Change Lever
 Install F/R change lever onto Trigger switch Fig. 13
 by placing the boss on Trigger switch between
 the prongs on F/R change lever as illustrated         F / R Change lever
 in Fig. 13.                                                                                       prongs
                                                  prongs                                                    boss




                                                      boss


                                                    Trigger switch
                                                                                                          P7/7
Circuit    diagram

  Color index of lead wires' sheath
   Black
   Red


                                                                                                   Red marking



     Battery holder                                        Switch                                  D/C motor




Wiring     diagram
 [1] Connecting Lead Wires with Motor                              Fig. 14
 Connect the lead wires with the terminals on Motor so that they                                   Red marking
 are placed on the side of Housing (L). (Fig. 14)

 [2] Wiring in Housing
 Route lead wires as illustrated in Fig. 15.

 [3] Connecting Lead Wires with Battery Holder
                                                                       Lead wire (red)
 Connect lead wires with the terminals on Battery holder as
 illustrated in Fig. 16.                                                      Lead wire (black)

 Fig. 15

                                                                     Do not put lead wires on
                                                                     this rib.


                     Gear assembly      D/C Motor




                                                              Hold the lead wires with
                                                              lead wire holder.

                                      Switch              Lead wire (black)

    Route the lead
    wire (red) through                                    Lead wire (red)
    the boss and the rib.
                                                          Battery holder

     Route the lead
     wire (black) through                                           Fig. 16
     the boss and the rib.
                                                                                                  Lead wire (black)
                                                                      Lead wire (red)



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
