Image preview - the first page of the document
8412D-TE


>> Download 8412D-TE documenatation <<

Text preview - extract from the document
T         ECHNICAL INFORMATION
          Models No.             8412D
                                                                                                              New Tool


          Description           Cordless Percussion-Driver Drill

CONCEPTION AND MAIN APPLICATIONS
Model 8412DH/DWH can be used in three way: as a hammer drill, drill or
driver.




                                                                                                                         225mm(8-7/8")
Electronic control allows constant speed and high power at any load.
Model 8412DH is sold with a battery cartridge 1201 but without a fast
charger.
Model 8412DWH includes a battery cartridge 1201 and a fast charger                  79mm(3-1/8")
DC1201.




                                                                                             313mm(12-3/8")
    Specifications
     DC Magnet Motor                               12V
     No Load Speed High                            0-1150 R/min.
                    Low                            0-370 R/min.
     Blows per      High                           0-12700
     Minute         Low                            0-4100
     Capacities     Steel                          13mm (1/2")
                    Concrete                       10mm (3/8')
                    wood                           24mm (15/16")
                    Wood Screw                     6.4mm x 55mm (1/4" x 2-3/16")
                    Machine Screw/Nut              M8 (5/16")
     Net weight                                    2.2kg (4.9lbs)


    Standard equipment
     Fast Charger DC1201 (8412DWH only), Battery Cartridge 1201, Phillips Bit, Plastic Carrying
     Case (8412DWH only).


    Optional accessories
     Drill Bit 1.5, 2, 3, 4, 5, 6 (for steel), Drill Bit 9, 12, 15 (for wood),
     Phillips Bit 1-65, 2-45, 2-65, 2-82, 2-110, 2-150, 2-250, 3-45, 3-65, 3-110,
     Slotted Bit 5-45, 5-82, 6-70, 6.35-45, 8-45, 8-70,
     Tungsten-carbide Tipped Bit 5-70, 6.5-80, 7.5-90, 8-120, 8.5-180, 9.5-120,
     Foam Polishing Pad 125, Rubber Pad Assembly, Wool Bonnet 100,
     Battery Cartridge 1200, 1201, Fast Charger DC1201, Blow-out Bulb 54



    Features and benefits
     1.   Refer to the attached sheet for more information.
      Adjustable torque setting 10 torque              One-touch pushbutton for
      settings (5 - 60 kg.cm; 0.4 - 4.3 ft.lbs)        change from "rotation only" to
      and drilling (max. torque:210 kg.cm;             "rotation with hammering"
      15.2 ft.lbs)                                                                               Large fan for efficient
                                                                                                 motor cooling


                                                                                                       Well-designed pistol grip
                                                                                                       handle makes bit
                                                                                                       centering easy


                                                                                                     Reversing switch for easy
                                                                                                     bit / screw removal
*Keyless drill chuck with snap-in lock
  system that prevents bit from
  slipping or being over-tightened.
*Insert bit can be installed if removing
  the existing drill chuck.              Speed change switch
                                         High: 0 - 1,150 R/min.
                                         Low: 0 - 370 R/min.
                                                                                                    Convenient hand-strap
