T        ECHNICAL INFORMATION
          Models No.                9015B
                                                                                                                  New Tool


          Description             125mm(5") Angle Grinder
                                  150mm(6") Angle Grinder

CONCEPTION AND MAIN APPLICATIONS                                                                    381
Model 9015B(and 9016B) has been developed aiming at                                                (15")
improving our most popular 5"(& 6") grinding model
9005B(9006B). Its main features are
1) Special anti-dust protections for armature, field and bearing




                                                                              (4-11/16")
   provide an extended service life of the grinder.




                                                                        118
2) A longer life of armature with ticker commutators.
3) More efficient cooling system for motor.
4) More comfortable and easier operation with larger trigger                                  139(5-1/2") 9015B
   switch and spindle lock button.                                                            169(6-5/8") 9016B




    Specifications
                                                                    Continuous Rating (W)
       Voltage (V)       Current (A)         Cycle (Hz)                                       Max. Output(W)
                                                                   Input          Output
           100                11               50/60               1050             550             1600
           110               9.6               50/60               1050             550             1600
           120               12.5              50/60               1370             800             1600
           200               5.5               50/60               1050             550             1600
           220               5.0               50/60               1050             550             1600
           230               4.8               50/60               1050             550             1600
           240               4.6               50/60               1050             550             1600

     No load speed(R.P.M.)                                 10000rpm (UK:11,500rpm)
     Size of depressed center wheel                        125mm(5")/150mm(6") x22mm(7.8") x6mm(1/4")
                                                            Outer diameter Arbor diameter Thickness
     Cord length                                           2.5m(8.2ft)
     Net weight A                                          2.4Kg(5.3lbs)
     Net weight B(9015B/9016B)                             2.9Kg(6.4lbs)/3.0Kg(6.6lbs)
     Net weight A ------------ without wheel,wheel cover, inner flange, lock nut and power supply cord
           Net weight B ------------ without wheel and power supply cord

    Standard equipment
     Lock Nut Wrench 35----------------------1 pc.
     Depressed Center Wheel 125-36--------1 pc. (9015B)
     Depressed Center Wheel 150-36--------1 pc. (9016B)
      The standard equipment may differ from country to country.


    Optional accessories
     Depressed Center Wheel 125/150-24,36
     Wire Cup Brush 90
     Wheel Cover (for Wire Cup Brush)
     Wheel Cover (for dust collect) for 9015B
     Rubber Pad
     Lock Nut 16-48
     Abrasive Disc 125/150-24,30,50,80, 100,120

     The standard equipment for the tools shown may differ form country to country
#9015B/#9016B
                                The commutator, made thicker, will provide a longer life of armature
                                    Special coil winding treatment(i.e.Varnish-treatment for
                                    armature, special taping treatment for field-coil) will
                                    protect a motor being damaged by abrasive particles.
       Large spindle lock                                                             More powerful motor
       can be easily preseed.
                                                                                      with specially designed fan for
                                                                                      efficient cooling system.




                                                                       Large and comfortable trigeer switch.

                                                            Labyrinth construction
                                                           employed at both sides of the armatures
       Gear housing can be screwed into the housing        (commutator and fan side) and the bearing
       at any direction by 90 especially for               (for the spindle) seals out dust/dirt.
       cutting operation.
Repair
(1) Replacing of armature
   1) Remove the wheel stone and the wheel cover, respectively.
   2) Remove the carbon brush.
   3) Disconnect the tapping screw PT5x30(4 pieces)for mounting the gear housing and motor housing and then
      remove the armature.
             1                      2             3                      4




                                                                                                 8


                        5               6                                                             9
                                                      7




  1)   Remove the wheel stone and the wheel cover, respectively.
  2)   Remove the tapping screw CT5x16(4 pieces) for mounting the bearing box.
  3)   The spiral bevel gear 33 is inserted in the spindle. Disassemble it in a way shown below.

  *To assemble the gear housing and gear housing cover on the motor housing, set in a way that un-processed edge
  face on the gear housing cover faces screw side of the spindle.

(2) Replacing of the spiral bevel gear 33
   1) Remove the wheel stone and the wheel cover, respectively.
   2) Remove the tapping screw CT5x16(4 pieces) for mounting the bearing box.
   3) The spiral bevel gear 33 is inserted in the spindle. Disassemble it in a way shown below.
                                        10                                   12
                                        11




                                                                                           13




                                                      20
                                                                                                14
                   21

                  22




                                                                                                15




                                                                                                     16
                                                                                                      17
                                             19                     18
  Turning the gear housing and gear housing cover in 4 directions together every 90 enables to change angle
  between wheel stone and handle.
  (Note) They can turn while the gear housing cover is housed in the motor housing.

  23                             24
                                                      25                  26
                                                                                       27




                               28




Circuit diagram
                                                                               31


                                           30
                   29




                                                                               32

                                      33




(3) Reference information : angle change between wheel stone and handle
