Image preview - the first page of the document

>> Download 9027-TE documenatation <<

Text preview - extract from the document
        Models No.                9027
                                                                                                                   New Tool

        Description               180 mm (7") Disc Grinder

CONCEPTION AND MAIN APPLICATIONS                                                            ")
Model 9027 is 180 mm (7") version of the existing Model                               8-3/16
9029. Models 9027F and 9027SF have a super flange. Models                      m  m(1
9027S and 9027SF have soft start feature.
(Note) Models 9027S and 9027SF are offered to 200V -
       240V areas and countries only.


                                                                Continuous Rating (W)                  Max.
      Voltage (V)      Current (A)        Cycle (Hz)                                                 Output(W)
                                                                Input           Output
          100              15.0              50/60              1,430              600                 2,600
          115              15.0              50/60              1,650              800                 2,600
          200              10.5              50/60              2,000            1,200                 3,500
          220               9.6              50/60              2,000            1,200                 3,500
          230               9.2              50/60              2,000            1,200                 3,500
          240               8.8              50/60              2,000            1,200                 3,500

     No load speed                               8,500 R/min.
     Capacities       Depressed Center Wheel     180mm (7")
                      Wire Cup. Brush            110mm (4-3/8")
     Net weight                                  5.4kg (11.9lbs)

   Standard equipment
     Lock Nut Wrench 35, Grip 35

    Optional accessories
     Depressed Center Wheel 24P, 36P, Inner Flange 47 (DIN spec. Super Flange), Inner
     Flange 78 (for cut-off wheel), Outer Flange 78 (for cut-off wheel), Wire Cup Brush 110, Loop Handle

    Features and benefits
    1. New type motor (powerful and durable motor) is employed to prevent motor burnout.
     2. Excellent dust-proof mechanism (dust-proof ball bearings, dust-proof labyrinth, etc. are built in the tool)
        assures long life of the tool.
     3. Large trigger switch with lock-on/off lever for increased maneuverability.
     4. Low profile gear housing for easy operation
     5. Switch handle swivels 90 degrees left or right for easy cut-offs.
     6. New side grip designed for comfort and no-slip cut-off work; attaches on top/either side.
     7. Automatic cut-out carbon brush (1 piece) protects armature.
     8. Double insulated for operator safety
     9. Soft-start feature minimized start-up shock (Models 9027S and 9027DF).
    10. Super Flange makes wheel removal "super" simple; easy lock nut removal (DIN type only).

    The standard equipment for the tools shown may differ from country to country.
