Image preview - the first page of the document



>> Download 9029-TE documenatation <<

Text preview - extract from the document

T       ECHNICAL INFORMATION
         Models No.               9029
                                                                                                                       New Tool


         Description             230mm (9") Disc Grinder




                                                                                                                         144mm
CONCEPTION AND MAIN APPLICATIONS                                                              462m
                                                                                                     m

Long-expected disc grinders are offered by Makita now. Their
power, maneuverability and dust-proof mechanism are
outstanding. Try them! They are ideal for both grinding and cut-
off jobs.

Model 9029S has soft start feature.
(Note)                                                                       24
                                                                                  4m
Model 9029S is offered to 200V-240V areas and countries only                           m



    Specifications
                                                                     Continuous Rating (W)
       Voltage (V)        Current (A)         Cycle (Hz)                                             Max. Output(W)
                                                                    Input          Output
          100                 15.0              50/60               1,430            600                   2,600
          115                 15.0              50/60               1,650            800                   2,600
          200                 10.5              50/60               1,430           1,200                  3,500
          220                  9.6              50/60               2,000           1,200                  3,500
          230                  9.2              50/60               2,000           1,200                  3,500
          240                  8.8              50/60               2,000           1,200                  3,500
    No load Speed: 6,600 R/min.
    Capacities
    Depressed Center Wheel: 230 mm (9")
    Wire Cup Brush       : 110 mm (4-3/8")
    Net weight: 5.5 kg (12.1 lbs)


    Standard equipment
     Lock Nut Wrench 35, Grip 35



    Optional accessories
     Dust Collecting Wheel Guard, Inner Flange 47 (DIN spec. Spur Flange),
     Depressed Center Wheel 24P, 36P, Inner Flange 78 (For cut-off wheel),
     Outer flange 78 (For cut-off wheel), Loop Handle, Wire Cup Brush 110


    Features and benefits
      1. New type motor (powerful and durable motor) is employed to prevent burnout.
      2. Excellent dust-proof mechanism (dust-proof ball bearings, dust-proof labyrinth, etc. are built in the tool)
         assures long life of the tool.
      3. Large trigger switch with lock-on/off lever for increased maneuverability.
      4. Low profile gear housing for easy operation.
      5. Switch handle can be rotated to either 90
