Image preview - the first page of the document
9035-TE


>> Download 9035-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION
         Models No.              9035
                                                                                                            New Tool


         Description             Finishing sander

        CONCEPTION AND MAIN APPLICATIONS
Develop to expand the sales market for home appliance
as the sister version of the model 9035SB.

                                                                                                          142




                                                                            93                    236




    Specifications
      Single-phase Voltage              Current                   Frequency              Consumed power
              100V                        2A                       50-60 Hz                   160 W

     No load speed                       10,000 R.P.M.
     Pad size                            93 x 185 mm
     Paper size                          93 x 228 mm
     Weight                              1.35 kg
     Cord length                         2.5 m


    Standard equipment
     Sanding paper #60, #100, #150, two pieces for each

    Optional accessories
     Sanding paper #60, #100, #150

    Features and benefits
      1. In addition to the light body weight of 1.35 kg, this machine is structured compactly.
      2. The powerful motor with the double insulation structure enables the safe operation.

    Repair
      Same as 9035SB




     The standard equipment for the tools shown may differ form country to country
