Image preview - the first page of the document
9035N-TE


>> Download 9035N-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.              9035N
                                                                                                   New Tool


     Description             Finishing Sander

CONCEPT AND MAIN APPLICATIONS
  Model 9035N has the switching arrangement for
  orbital and straight movement. The orbital
  movementis for general finishing, and the straight
  movement is for grain finishing.




                                                                         148
                                                                                               5
                                                                                          23
                                                                               93
  Specifications
                                                              Continuous rating
     Voltage(V)       Current(A)         Cycle(Hz)                                    Max.output(W)
                                                           Input(W)       Output(W)
         100              1.7               50/60            130              30           40
         115              1.5               50/60            130              30           40
         200              0.9               50/60            130              30           40
         220              0.8               50/60            130              30           40
         230              0.7               50/60            130              30           40
         240              0.7               50/60            130              30           40

   No load speed (R.P.M.)                  7000/min.
   Abrasive paper size                     93 x 228 mm
   Pad size                                93 x 185mm
   Net weight                              1.45 kg
   Power supply cord                       2.5 m


  Standard equipment
  Sanding paper 93-60 2 sheets
  Sanding paper 93-100 2 sheets
  Sanding paper 93-150 2 sheets


  Optional accessories
  Sanding paper 93-60
  Sanding paper 93-10
  Sanding paper 93-150

  Features and benefits
  1. You can switch the movement with one touch of a finger.
  2. Use straight movement for grain finishing.
  3. This model is light and compact.
  4. Double insulated structure promises safe operation.

  Capacity
  1. Sanding efficiency is almost the same as 9035SB, 9035, B%D(7436).



  The standard equipment for the tools shown may differ form country to country
  The standard equipment for the tools shown may differ form country to country
Repair
1.   Remove screws fixing the base at 4 points to detach the base.
2.   Except the above step, follow the procedures for 9035SB and 9035.
