Image preview - the first page of the document
9036-TE


>> Download 9036-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
   Models No.               9036
                                                                                                                    PRODUCT
                                                                                                                      P1/2

   Description              Finishing sander                                                             L
CONCEPTION AND MAIN APPLICATIONS
   The new finishing sander has been launched to the market
   wit the following features and benefits.
   * Easy to change sanding papers with large paper clamp
     assembled in front of the product
   * Equipped with dust extraction nozzle for connecting to
     MAKITA vacuum cleaner.
                                                                                                                        H
                                           Dimensions : mm ( " )
                                      Length ( L ) 238 (9-3/8)                      W
                                      Width ( W )   93 (3-5/8)
                                      Height ( H ) 151 (5-15/16)

 Specification
                                                                         Continuous Rating (W)
      Voltage (V)          Current (A)          Cycle (Hz)                                                   Max. Output(W)
                                                                        Input           Output
         115                  1.8                  50 / 60               180              90                       95
         200                  1.1                  50 / 60               180              90                       95
         220                  1.0                  50 / 60               180              90                       95
         230                  0.9                  50 / 60               180              90                       95
         240                  0.9                  50 / 60               180              90                       95

    Pad size : mm ( " )                      93 (3-5/8) x 185 (7-1/4)
    Paper size : mm ( " )                    93 (3-5/8) x 228 (9)
   Paper attaching Paper clamp
   system           Hook and loop
   Orbit per min : opm = min-1                     12,000
   Orbit diameter : mm ( " )                       2.3 (3/32)
   Dust        by Through the pad
   extracting with Vacuum cleaner
    Protection from electric shock           by double insulation
    Cord length : m ( " )                         2.0 (6.6)
    Net weight : Kg (lbs)                         1.4 (3.0)




 Standard equipment
   * Abrasive papers .................... 6 pcs. (grit 60 : 2 pcs. grit 80 : 2 pcs. grit 100 : 2 pcs.)



   < Note > The standard equipment for the tool shown may differ from country to country.


 Optional      accessories
   * Abrasive paper 93- 60               * Punch plate
   * Abrasive paper 93- 80               * Hose complete 19 - 2.5
   * Abrasive paper 93- 100
   * Abrasive paper 93- 150
Features      and benefits                                                                                                                    P2/2
                                           9036


                                                                                                                Dust extraction nozzle
                                                                                                                for connection with vacuum
                                                                                                                cleaner


     The stabilized sanding work
     thanks to low center of gravity.




Punch plate (optional accessory)
for allowing through the pad                                                                                    Big paper clamp levers for easy
dust extraction                                                                                                 replacing abrasive papers




Comparison        of products
                                                                                   30g
   Comparison of the amount                                                                  MAKITA 9036
   of sanding dust removed                                                                                                                        26.3 g
                                                                                             MAKITA 9035
                                                  Amount of sanding dust removed




                                                                                                                                                  24.2 g
   Conditions                                                                                Competitor A Model A
   * Material : Pine (produced in New Zealand)
   * Grit of the abrasive paper : WA60                                                                                                            18.6 g
                                                                                                             17.8 g
                                                                                                                        16.5 g
                                                                                   15g
                                                                                                                       12.8 g




                                                                                    0
                                                                                         0                      15 min.                      30 min.
                                                                                                              Operating time

            Model No.                                   MAKITA                                                                      Competitor A
                                                9036                                                          9035                      Model A
   Orbit per min : opm = min-1                12,000                                                        10,000                     11,000
   Power Input : (W)                             180                                                           160                         180
   Paper size : mm ( " )                   93 (3-5/8) x 228 (9)                                        93 (3-5/8) x 228 (9)       93 (3-5/8) x 228 (9)
   Dust extraction fixture           Yes (with optional accessory)                                              No                         No
   Dimensions           Length ( L )         238 (9-3/8)                                                  235 (9-1/4)                 243 (9-9/16)
          : mm ( " ) Width ( W )              93 (3-5/8)                                                    93 (3-5/8)                  90 (3-1/2)
                        Height ( H )         151 (5-15/16)                                                143 (5-5/8)                 178 (7)
   Net weight : Kg (lbs)                      1.4 (3.0)                                                      1.35 (3.0)                 1.9 (4.2)
