Image preview - the first page of the document
9031-TE


>> Download 9031-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION
         Models No.                 9031
                                                                                                                    New Tool


         Description                30 mm (1-3/16") Belt Sander

CONCEPTION AND MAIN APPLICATIONS
Model 9031 is an improved version of the existing Model 9030.
* More powerful                                                                                          170 mm (6-11/16")
* Equipped with a speed adjusting dial
* Can be connected to Makita vacuum cleaner/dust collector



                                                                   90 mm (3-1/2")


                                                                                          380 mm (15")




    Specifications
                                                                  Continuous Rating (W)
       Voltage (V)       Current (A)        Cycle (Hz)                                           Max. Output(W)
                                                                 Input          Output
           100                5.8              50/60              550             300                        520
           115                5.0              50/60              550             300                        520
           220                2.6              50/60              550             300                        520
           230                2.5              50/60              550             300                        520
           240                2.4              50/60              550             300                        520


     Belt size                                  30 mm x 533mm (1-3/16" x 21")
     Belt speed                                 200 m/min. 1,000 m/min. (660 ft/mm. - 3,300 ft/min.)
     Net Weight                                 2.1 kg (4.6 lbs)


    Standard equipment
     Abrasive belts 533-40, 60, 80, 100, 120 (AA type for wood, iron and steel)


    Optional accessories
     Abrasive belts 533-40, 60, 80, 100, 120, 150, 240 (AA type for wood, iron and steel), Abrasive belts 533-40, 60, 80,
     100, 120, 150 240 (CC type for stone and plastics), Hose 19

    Features and benefits
      1.Double insulated
      2.Refer to the attached sheet for more information.




     The standard equipment for the tools shown may differ form country to country
                                                    Makita powerful motor

              Slim handle for easy,comfort-
              able gripping




Speed adjusting dial:
Belt running speed can be adjusted
between 200m/min.(660 ft/min.)
and 1,000m/min.(3,300 ft/min.)                                              More durable front pulley
by turning this dial.
                                     Makita vacuum cleaner/dust
                                     collector can be connected
                                     to this nozzle.
