Image preview - the first page of the document
9045N-TE


>> Download 9045N-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION
       Models No.             9045N
                                                                                                       New Tool


       Description           MAKITA Finishing sander

CONCEPT AND MAIN APPLICATIONS
    The model 9045N has been developed as the new
    model of the current type of 9045. Unlike the
    conventional type, the dust collecting unit is
    installed and the machine vibration has been
    minimized to extremely improve the working efficiency.




                                                                                    Appearace layout



   Specifications
      Volt                    Current                  Frequency           Continuous rating input
      100V                     5.5 A                    50-60 Hz                 520 W

Abrasive paper size                  114 x 280 mm
Pad size                             114 x 234 mm
No load speed (R.P.M.)               10000 rpm
Overall length                       268 x 132 x 160 mm
Net weight                           2.8 kg
Power supply cord                    2.5 m


   Standard equipment
    Abrasive paper --- #60, #100, #120, #150, #180 two pieces for each


   Optional accessories
   Parts no                   Names                                  Applications
7425019         Abrasive paper 114-60                 For wood #60, 10 pieces contained
7425027         Abrasive paper 114-100                For wood #100, 10 pieces contained
7425035         Abrasive paper 114-120                For wood #120, 10 pieces contained
7425043         Abrasive paper 114-150                For wood #150, 10 pieces contained
7425051         Abrasive paper 114-180                For wood #180, 10 pieces contained




    The standard equipment for the tools shown may differ form country to country
Features and benefits
(1) High working efficiency and beautiful finishing
    The RPM is not changed from conventional type of #9045, but the decentering amount has been increased from
    0.75 to 1.2 mm to improve the grinding efficiency.(See the 5. Capacity for comparison of efficiency.)
(2) By the belt driving the torque of output shaft has been increased
    Since the pad rotation is directly connected with the motor in the conventional type, the motor rotation is
    suppressed at low and the torque is decreased, and if the machine body is pressed, the rotation is extremely
    lowered and it may make users to think that the power is low. On the other hand, the speed reducing function by
    the belt driving in the new type has enabled the torque increasing for the output shaft.
(3) Less vibration caused against the body
    Compared with he conventional type, the vibration has been extremely minimized.
(4) Dust absorbing unit mounted
    The dust absorbing unit built in this machine provides the clean and healthy working.
(5) Dust and water proof structure
    Except for the motor, the dust and water proof structures are built in.
    Accordingly the service life of the bearing inside the base(problem occurred in the conventional type before) and
    the endurance has been extremely improved.
    Through the use of water proof paper in addition to this water proof mechanism, the water grinding also becomes
possible.
(6) Corner grinding possible
    If the frame cover on the duct absorbing unit is removed, it enables grinding using the full corner.
(7) Double insulation structure



Repair
(1) Disassembling
(a) Remove the steel band(for holding the rubber sleeve)mounted on the base from between the base and the frame.
(b) Remove the push buttons(2 pieces at back/forth) protruded above the top of frame.
(c) Remove the bearing retainer at center on the base. To disconnect it, place the minus screw driver on the cracked
    point on the bearing retainer and turn the bearing retainer in left.
(d) Remove the pan head screw M5x12 holding the balance weight on the bearing #6003ZZ. At this time insert the
    minus screw driver into the rubber sleeve to protect the balance weight from turning for easy disconnection.
(e) Next disconnect the base. If hard to disconnect it due to the base tightly connected, insert the screw driver
    between the frame and the base and disconnect while slightly twisting the driver.

(2) Cautions in assembling
(a) Slightly grease the Grease(Albania No.2)on the needle bearing housed in the frame.
(b) When assembling the base, assemble it so that the face at base side can be parallel to the face at the frame side.
