Image preview - the first page of the document
9047S-TE


>> Download 9047S-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION
    Models No.             9047S
                                                                                                          New Tool




                                                                                                            139 )
    Description             180mm Dish Grinder




                                                                                                                /2"
                                                                                              ")
                                                                                       18-1/2




                                                                                                           (5-1
                                                                                  470(
CONCEPTION AND MAIN APPLICATIONS
180mm disk grinder based on 9049S , adding 180mm wheel.
9047S F : 9047 with Super flange




                                                                  20 /8")
                                                                  (7
                                                                    0
                                                                     -7
   Specifications
                                                               Consuming              Nominal
        Voltage (V)         Current(A)          Cycle(Hz)      power(W)               output(W)      Max. output(W)
             100                15.0                  50/60      1,430                 600                2,600
             120                15.0                  50/60      1,650                 850                2,600
             200                11.0                  50/60      2,100                1,350               3,500
             220                10.0                  50/60      2,100                1,350               3,500
             230                 9.6                  50/60      2,100                1,350               3,500
             240                 9.2                  50/60      2,100                1,350               3,500

       Motor                                                  Series commutator motor
       Speed at no load                                       8500 rpm
       Grinding wheel                                         Outer dia.180 x Inner dia. 22.23 x Thickness 6
                              mm(inch)
                                                              (7" x 7/8" x 1/4")


    Standard       equipment
     Lock nut wrench 35
     Grip


    Optional       accesories
     Inner flange 47 set ( DIN spec., Super flange)
     Depressed center wheel
     Diamond wheel
     Wire cup brush 110 set
     Loop handle
     Cut-off wheel
    With Torque limiter                           Motor of which durability
                                                  has been improved
   Prevents Lock nut from too much
   fastening caused by starting and              Durability has been improved by
   heavy load operation , and makes              making measures against Motor wire
   removing Wheel easier.                        cutting and Dust particles owing to
                                                 Varnish treatment of Armature and
                                                                                             With Soft start
                                                 Taping treatment of Field.




                                                                               Large switch of good operativity




                                                              Bearing part of Dust-proof structure
With Super flange
                                                             Labyrinth structure ( Maze system to
 ( only F spec. model)
                                                             prevent dusts from entering) is applied
                                                             in Commutator side of Armature and
                                                             Fan side of Bearing.


                     Gear housing turning 90
