Image preview - the first page of the document
>> Download 9049S-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Models No. 9049S
New Tool
Description 230mm Dish Grinder
139 )
/2"
CONCEPTION AND MAIN APPLICATIONS 8-1
/2")
(5-1
(1
470
230mm Disk grinder based on #9049, adding Lift start mechanism and
decreasing the impact in starting for easier operation.
#9049SF: 9049S with Super flange
24 /8")
(9
4
-5
Specifications
Consuming Nominal
Voltage (V) Current(A) Cycle(Hz) power(W) output(W) Max. output(W)
100 15.0 50/60 1,430 600 2,600
120 15.0 50/60 1,650 850 2,600
200 11.0 50/60 2,100 1,350 3,500
220 10.0 50/60 2,100 1,350 3,500
230 9.6 50/60 2,100 1,350 3,500
240 9.2 50/60 2,100 1,350 3,500
Motor Series commutator motor
Speed at no load 6600 rpm
Grinding wheel Outer dia.230 x Inner dia. 22.23 x Thickness 6
mm(inch)
(9" x 7/8" x 1/4")
Standard equipment
Lock nut wrench 35
Grip
Optional accesories
Inner flange 47 set ( DIN spec., Super flange)
Depressed center wheel
Diamond wheel
Wire cup brush 110 set
Dust collecting wheel cover
Loop handle
With Torque limiter Motor of which durability
has been improved
Prevents Lock nut from too much
fastening caused by starting and Durability has been improved by
heavy load operation , and makes making measures against Motor wire
removing Wheel easier. cutting and Dust particles owing to
Varnish treatment of Armature and
With Soft start
Taping treatment of Field.
Large switch of good operativity
Bearing part of Dust-proof structure
With Super flange
Labyrinth structure ( Maze system to
( only F spec. model)
prevent dusts from entering) is applied
in Commutator side of Armature and
Fan side of Bearing.
Gear housing turning 90◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
