Image preview - the first page of the document



>> Download 9059-TE documenatation <<

Text preview - extract from the document

T      ECHNICAL INFORMATION
        Models No.                9059
                                                                                                             New Tool


        Description               230mm(9") Disc grinder

CONCEPTION AND MAIN APPLICATIONS                                                     470(18 1
                                                                                              /2")

This model is a modified version of model 9039 and is an upper class




                                                                                                                 139(5 1/2")
product of 9049.
Super flange is added to model 9059F.




                                                         24
                                                          4(9
                                                              5/8
                                                                ")
    Specifications
                                                                     Continuous Rating (W)             Max.
      Voltage (V)      Current (A)        Cycle (Hz)                 Input           Output          Output(W)
          100               15               50/60                   1430              700             3000
          120               15               50/60                   1650              950             3000
          200               12               50/60                   2300             1500             4600
          220               11               50/60                   2300             1500             4600
          230              10.5              50/60                   2300             1500             4600
          240               10               50/60                   2300             1500             4600


     No load speed         6600/min
     Wheel size            230mm (9")
     Net weight            5.1kg (11.2lbs)
     Power supply cord     2.5m (8.2ft)




    Standard equipment
       Lock nut wrench 35, Grip


    Optional accessories
     Inner flange 47 set (DIN standard, super flange), Offset grindstone, Diamond wheel,
     Wire cup brush 110 set, Wheel cover for dust catcher, Loop handle
                                              Durable motor
                                     Armature is vanish processed and
                                     the field is protected by taping
                                     to prevent motor from burnout.
                                     Also dust-proof mechanism
                                     improves the durability.
Torque limiter prevents excessive                                                    Soft start mechanism
tightening of lock nut at the time                                                     (For S type only)
of start-up or during no-load
operation.




                                                                               Large switch assures operability


  Super flange                                                    Dust-proof bearing section
(For F type only)                                                Labyrinth structure that prevents dust intrusion
                                                                 is furnished on commuter side of armature and
                                                                 bearings of fan side.
Gear housing can be mounted
by each 90-degree angle
(suitable for cutting operation)
Repair
Procedures corresponds to 9049.
