Image preview - the first page of the document



>> Download 9069-TE documenatation <<

Text preview - extract from the document

T       ECHNICAL INFORMATION                                                                                       Product

          For Models           9067, 9067L, 9067S, 9069, 9069S
          Description         180mm/230mm Angle Grinders

CONCEPTION AND MAIN APPLICATIONS                                                                      458mm(18")
These models are angle grinders of wheel size
180mm/230mm(7"/9") designed as economy type
of sister models of Model 9047/9049 series.                                   139mm(1/2")
By suppressing maximum output of motor, Torque
limiter is not neccessary for these models.
Model 9067S/ 9069S are with soft start function
versions of Model 9067/9069.
Model 9067L is low speed version of Model 9067.        250mm(9-7/8") --- 906
                                                                             9/9069S

                                                                 200mm(7-7/8") --- 9067/9067L/9067S




         Specifications
                                                                               Continuous Rating(W)
        Voltage (V)          Current(A)          Cycle(Hz)                                                     Max. output(W)
                                                                             Input           Output
            115                  15                  50/60                   1650               900                2600
            220                  9.6                 50/60                   2000              1100                2900
            230                  9.2                 50/60                   2000              1100                2900
            240                  8.8                 50/60                   2000              1100                2900

                           9067/9067S       8500 rpm
      No load speed
                           9067L/9069/9069S 6600 rpm
                            9067L/9069          6000 rpm        (for only U.S.A. and Canada)
      Depressed            9067/9067L/9067S Outer dia.:180mm(9") X Arbor dia.:22.23mm(7/8") X Thickness:6mm(1/4")
      center wheel         9069/9069S       Outer dia.:230mm(7") X Arbor dia.:22.23mm(7/8") X Thickness:6mm(1/4")
      Net weight                            4.2Kg(9.3lbs)
      Cord length                           2.5m(8.2ft)

        Standard      equipment
         Lock nut wrench 35
         Lock nut wrench 28 (9067L/9069: for only U.S.A. and Canada)
          The standard equipment may differ from country to country.

        Optional      accesories
          9067/9067L/9067S Super Flange,
                            Depressed center wheel 24P/36P,
                            Inner Flange78 (for cutting wheel),         Outer Flange78 (for cutting wheel)
                            Wire Cup Brush 110 ,
                            Grip set (loop handle)
          9069/9069S       Super Flange,
                            Depressed center wheel 24P/36P,
                            Inner Flange 78 (for cutting wheel),         Outer Flange78 (for cutting wheel)
                            Wire Cup Brush110,
                            Grip Set (loop handle)

        Feautures      and benefits
         1. Double insulated
         2. See the sheets attached for more information
9067,9067L,9067S,9069,9069S

                               Long life motor


      Large spindle lock
  Shape is suitable for
  handling easily by
  finger with glove.




                                             Large trigger switch




                                Better dust protection
                                Ball bearings with higher dust sealing and labyrinth structure
                                at both end of armature and outside of spindle

    Gear housing may be
    re-attached at every 90
